Citation: Xi Zifan, Yuan Fanglong, Wang Zifei, Li Shuhua, Fan Louzhen. Highly Efficient and Stable Full-Color Random Lasing Emission Based on Carbon Quantum Dots[J]. Acta Chimica Sinica, ;2018, 76(6): 460-466. doi: 10.6023/A18020048 shu

Highly Efficient and Stable Full-Color Random Lasing Emission Based on Carbon Quantum Dots

College of Chemistry, Beijing Normal University, Beijing 100875

Corresponding author: Fan Louzhen, lzfan@bnu.edu.cn
Received Date: 1 February 2018
Available Online: 8 June 2018
Fund Project: Project supported by the National Natural Science Foundation of China (Key program, No. 21233003; General Program, No. 21573019), and the Fundamental Research Funds for the Central Universities

Figures(7)

The emerging fluorescent carbon quantum dots (CQDs) have shown enormous potentials in optoelectronic applications owing to their outstanding characteristics, such as tunable stable fluorescence emission, low cost, and environment-friendliness. However, the fluorescence of most reported CQDs is dominated by surface defects, which are in general energy dissipative, hard to support lasing emission. We have previously reported the bandgap emission CQDs from blue to red with a quantum yield (QY) over 50%, which is the highest value reported for bandgap emission CQDs. The bandgap transitions in CQDs were further confirmed by size-dependent optical properties through tansmission electron microscopy (TEM), which show uniform distribution nanoparticles with averge sizes of about 1.95, 2.41, 5.0 nm for blue, green and red CQDs, and their typical high-resolution TEM (HRTEM) images further indicates that most of the CQDs exhibit uniform atomic arrangements with high degree of crystallinity. By taking advantage of the high QY of CQDs, monochrome CQDs-based random lasing with low excitation threshold have been realized by using Au-Ag bimetallic porous nanowires as scatterers for the first time. The Au-Ag bimetallic porous nanowires possess a rough surface with Au nanoparticles and abundant nanogaps, leading to the extremely broadband surface plasmonic resonance peaks over the whole visible spectral range, which is benefit for efficient random lasing. The thresholds of the monochrome CQDs-based random lasers reached about 0.27, 0.21, 0.58 MW/cm² for blue, green and red, respectively. The full width at half maximum (FWHM) of the monochrome CQDs-based random lasers reached about 2.5, 1.9, 2.3 nm for blue, green and red, which is even comparable to the well-developed semiconductor QDs-based random lasers. The obtained random lasers show substantial stable emission color, which is of great significance for lasing display and lighting technology. Furthermore, white lasing with a CIE coordinate at (0.32, 0.33) was first demonstrated by combining red, green, blue fluorescent CQDs. This work does serve the purpose of understanding and providing significant opportunities for further improvements of CQDs-based lasers.
- carbon quantum dots,
- bandgap emission,
- random lasing,
- full-color,
- white laser
