Template-Assisted Preparation and Lithium Storage Performance of Nitrogen Doped Porous Carbon Sheets

a.
Xinjiang Uygur Autonomous Region Key Laboratory of Clean Coal Conversion and Chemical Process, Xinjiang University, Urumqi 830046
b.
Department of Materials Science and Engineering, Jilin University, Changchun 130025

Corresponding author: Mi Hongyu, mmihongyu@163.com
Received Date: 18 September 2017
Available Online: 22 March 2018
Fund Project: Project supported by the National Natural Science Foundation of China (No. 21563029) and the Natural Science Foundation of Xinjiang Uygur Autonomous Region (No. 2014211A015)the Natural Science Foundation of Xinjiang Uygur Autonomous Region 2014211A015the National Natural Science Foundation of China 21563029

Figures(8)

Nitrogen doped porous carbon sheets (NPCSs) having high lithium storage performance were successfully prepared by a template-assisted approach using magnesium oxide/melamine/polyethylene glycol (MgO/melamine/PEG) as raw materials. In a typical procedure, the precursor, which consisted of MgO, melamine and PEG in a mass ratio of 7:3:10, was carbonized at 700℃ for 3 h in a temperature-programmed tubular furnace under N₂ flow with a heating rate of 5℃·min^-1. The intermediate was immersed into 3 mol·L^-1 HCl solution for several times to remove MgO. Subsequently, the sample was rinsed with water and ethanol until a neutral pH was obtained, and then dried at 80℃ in a vacuum oven. The sample was systematically characterized and analyzed by Fourier transform infrared spectrometer (FTIR), X-ray powder diffractometer (XRD), X-ray photoelectron spectrometer (XPS), scanning electron microscope (SEM), transmission electron microscope (TEM), cyclic voltammetry (CV), galvanostatic charge/discharge (GCD) and electrochemical impedance spectroscopy (EIS). The results indicated that NPCSs showed an interconnected porous carbon sheet networks, showing relatively high specific surface area (370.8 m²·g^-1), hierarchical pore channels, and high nitrogen content (8.5 at%). Such a continuous porous structure could enhance the electron transport on three-dimensional direction, shorten the diffusion distance of lithium ions, enlarge the interface area between lithium ion and electrolyte, and provide the place for the accommodation of lithium ions. Additionally, high N-doping level in NPCSs could provide numerous activated sites for the intercalation and deintercalation of lithium ions, and enhance the electronic conductivity. Based on the unique structure, NPCSs electrode could exhibit high initial reversible specific capacities (after excluding the contribution of acetylene black, 914 mAh·g^-1 at 100 mA·g^-1) and good cycling stability (still remaining a specific capacity of 523 mAh·g^-1 at 1000 mA·g^-1 up to 300 cycles). Moreover, NPCSs displayed high rate capability with a reversible capacity of 355 mAh·g^-1 at a current density of 3000 mA·g^-1. Therefore, the NPCSs obtained are expectable to be widely used as anode material in lithium-ion batteries.
- porous carbon sheet,
- carbonization-etching method,
- anode,
- Lithium-ion battery
