Citation: Li Qi, Xu Han, Tong Yexiang, Li Gaoren. Pt Tube-in-Tube Arrays as HighPerformance Electrocatalysts for Direct Methanol Fuel Cell[J]. Acta Chimica Sinica, ;2017, 75(2): 193-198. doi: 10.6023/A16070337 shu

Pt Tube-in-Tube Arrays as HighPerformance Electrocatalysts for Direct Methanol Fuel Cell

Li Qi ,
Xu Han ,
Tong Yexiang ^*,, ,
Li Gaoren ^*,,

MOE Laboratory of Bioinorganic and Synthetic Chemistry, KLGHEI of Environment and Energy Chemistry, School of Chemistry, Sun Yat-sen University, Guangzhou 510275, China

Corresponding author: Tong Yexiang, sysutong@sina.cn Li Gaoren, ligaoren@mail.sysu.edu.cn
Received Date: 13 July 2016

Fund Project: and Natural Science Foundation of Guangdong Province S2013020012833Project supported by the National Natural Science Foundation of China 51173212

Figures(11)

The Pt tube-in-tube arrays (TTAs) were designed and synthesized by ZnO template-assisted electrodeposition. As a robust integrated 3D electrocatalyst with high utilization rate and fast transport of electroactive species, the Pt TTAs exhibit a high electrochemically active surface area (ECSA) of 64.9 m²/gPt. Compared with Pt NTAs and commercial Pt/C catalyst, the Pt TTAs exhibit much improved electrocatalytic activity and durability for methanol oxidation. In addition, the Pt TTAs as electrocatalysts exhibit superior CO poisoning tolerance. This work shows the significant progress of Pt-based electrocatalysts with high-performance for direct methanol fuel cells.
- Pt,
- electrocatalyst,
- tube-in-tube,
- methanol oxidation,
- electroactivity,
- durability
