Citation: Yu Kuan, Gao Beiling, Ding Hanfeng. Asymmetric Total Synthesis and Absolute Configuration Reassignment of Indole Alkaloid (+)-Alsmaphorazine D[J]. Acta Chimica Sinica, ;2016, 74(5): 410-414. doi: 10.6023/A16020102 shu

Asymmetric Total Synthesis and Absolute Configuration Reassignment of Indole Alkaloid (+)-Alsmaphorazine D

Yu Kuan ^† ,
Gao Beiling ^† ,
Ding Hanfeng ^*,,

1.
Department of Chemistry, Zhejiang University, Hangzhou 310028

Corresponding author: Ding Hanfeng, hfding@zju.edu.cn
Received Date: 25 February 2016

Fund Project: the Zhejiang Natural Science Fund for Distinguished Young Scholars LR16B020001the National Natural Science Foundation of China 21472167

Figures(6)

The first asymmetric total synthesis of (+)-alsmaphorazine D has been achieved through a traceless chirality transfer strategy, which also enabled absolute configuration reassignment of the natural product. Key steps of this efficient approach entail a catalytic oxidative cyclization [To a solution of indoline ester 8 (5.82 g, 10 mmol) in AcOH (100 mL) were added CAN (550 mg, 1 mmol) and NaOAc (1.64 g, 20 mmol). The reaction vessel was exposed to air through a CaCl₂ tube. The resulting mixture was stirred at 110 ℃ for 12 h before it was concentrated in vacuo. The residue was diluted with H₂O, neutralized with NaHCO₃ (sat. aq.) and extracted with EtOAc. The combined organic layers were washed with brine, dried (Na₂SO₄) and concentrated in vacuo. Flash column chromatography (silica gel, hexanes/EtOAc, V:V=4:1) afforded δ-lactamindole 7 (4.34 g, 75%) as a white amorphous solid], a diastereoselective oxidative cyclic aminal formation [To a stirred solution of mono-ester 13 (5.20 g, 10 mmol, dr=1:1) in acetone (100 mL) at 0 ℃ was added NaHCO₃ (100 mL, sat. aq.). The resulting mixture was stirred for 0.5 h before it was added oxone (12.28 g, 20 mmol) slowly. The reaction mixture was stirred at 0 ℃ for an additional 2 h before it was diluted with H₂O. The aqueous layer was extracted with CH₂Cl₂. The combined organic layers were washed with brine, dried (Na₂SO₄) and concentrated in vacuo. Flash column chromatography (silica gel, hexanes/EtOAc, V:V=3:1) afforded pyrroloindole 6' (1.61 g, 71%) as a white amorphous solid] and an intramolecular radical cyclization [To a stirred solution of ent-5 (250 mg, 0.47 mmol) in benzene (5 mL) at 80 ℃ were added n-Bu₃SnH (152 μL, 0.56 mmol) and AIBN (5 μL, 0.047 mmol). The resulting mixture was stirred for 0.5 h before it was concentrated in vacuo. Flash column chromatography (silica gel, hexanes/EtOAc, V:V=１:1) afforded C(16)-epi-ent-4 (213 mg, 72%) as a colorless oil.].
- alkaloid,
- total synthesis,
- tetracyclic system,
- oxidative cyclization,
- radical reaction
1. [1]
  Marini-Bettolo, G. B.; Nicoletti, M.; Messana, I.; Patamia, M.; Galeffi, C.; Oguakwa, J. U.; Portalone, G.; Vaciago, A. Tetrahedron 1983, 39, 323.(b) Ghedira, K.; Zeches-Hanrot, M.; Richard, B.; Massiot, G.; Le Men-Olivier, L.; Sevenet, T.; Goh, S. H. Phytochemistry 1988, 27, 3955.(c) Cai, X. H.; Du, Z. Z.; Luo, X. D. Org. Lett. 2007, 9, 1817.
2. [2]
  Kamarajan, P.; Sekar, N.; Mathuram, V.; Govindasamy, S. Biochem. Int. 1991, 25, 491.(b) Saraswathi, V.; Subramanian, S.; Ramamoorthy, N.; Mathuram, V.; Govindasamy, S. Med. Sci. Res. 1997, 25, 167.(c) Husain, K.; Jantan, I.; Kamaruddin, N.; Said, I. M.; Aimi, N.; Takayama, H. Phytochemistry 2001, 57, 603.(d) Khan, M. R.; Omoloso, A. D.; Kihara, M. Fitoterapia 2003, 74, 736.(e) Gupta, R. S.; Bhatnager, A. K.; Joshi, Y. C.; Sharma, M. C.; Khushalani, V.; Kachhawa, J. B. S. Pharmacology 2005, 75, 57.(f) Jagetia, G. C.; Baliga, M. S. Phytother. Res. 2006, 20, 103.
3. [3]
  For reviews, see: (a) Liu, J.-L. Chin. J. Org. Chem. 2003, 23, 784. (刘建利, 有机化学, 2003, 23, 784).(b) Zhou, H.; Liu, J.; Wang, C. Chin. J. Org. Chem. 2010, 30, 1305. (周华凤, 刘建利, 王翠玲, 有机化学, 2010, 30, 1305).(c) Wang, X.; Liu, J.; Huang, X.; Wang, C. Chin. J. Org. Chem. 2012, 32, 420. (王学军, 刘建利, 黄新炜, 王翠玲, 有机化学, 2012, 32, 420).(d) Li, S.; Han, J.; Li, A. Acta Chim. Sinica 2013, 71, 295. (李森, 韩静, 李昂, 化学学报, 2013, 71, 295).
4. [4]
  Koyama, K.; Hirasawa, Y.; Nugroho, A. E.; Kaneda, T.; Hoe, T. C.; Chan, K.-L.; Morita, H. Tetrahedron 2012, 68, 1502. For the isolation of alsmaphorazines A and B, see:(b) Koyama, K.; Hirasawa, Y.; Nugroho, A. E.; Hosoya, T.; Hoe, T. C.; Chan, K.-L.; Morita, H. Org. Lett. 2010, 12, 4188.
5. [5]
  Zhu, C.; Liu, Z.; Chen, G.; Zhang, K.; Ding, H. Angew. Chem., Int. Ed. 2015, 54, 879. For the total synthesis of (±)-alsmaphorazine B, see:(b) Hong, A. Y.; Vanderwal, C. D. J. Am. Chem. Soc. 2015, 137, 7306.
6. [6]
  Liu, X.; Cook, J. M. Org. Lett. 2001, 3, 4023.(b) Liao, X.; Zhou, H.; Wearing, X. Z.; Ma, J.; Cook, J. M. Org. Lett. 2005, 7, 3501.(c) Yin, W.; Kabir, M. S.; Wang, Z.; Rallapalli, S. K.; Ma, J.; Cook, J. M. J. Org. Chem. 2010, 75, 3339.(d) Edwankar, R. V.; Edwankar, C. R.; Deschamps, J.; Cook, J. M. Org. Lett. 2011, 13, 5216.
7. [7]
  Kamenecka, T. M.; Danishefsky, S. J. Chem. Eur. J. 2001, 7, 41.(b) Trzupek, J. D.; Lee, D.; Crowley, B. M.; Marathias, V. M.; Danishefsky, S. J. J. Am. Chem. Soc. 2010, 132, 8506.
8. [8]
  Peng, Q.-L.; Luo, S.-P.; Xia, X.-E.; Liu, L.-X.; Huang, P.-Q. Chem. Commun. 2014, 50, 1986.(b) Mao, Z.-Y.; Geng, H.; Zhang, T.-T.; Ruan, Y.-P.; Ye, J.-L.; Huang, P.-Q. Org. Chem. Front. 2016, 3, 24.
9. [9]
  For selected examples, see: (a) Kamenecka, T. M.; Danishefsky, S. J. Angew. Chem., Int. Ed. 1998, 37, 2995.(b) Baran, P. S.; Guerrero, C. A.; Corey, E. J. J. Am. Chem. Soc. 2003, 125, 5628.(c) Umehara, A.; Ueda, H.; Tokuyama, H. Org. Lett. 2014, 16, 2526.
10. [10]
  Snider, B. B. Chem. Rev. 1996, 96, 339.(b) Tsai, A.-I.; Lin, C.-H.; Chuang, C.-P. Heterocycles 2005, 65, 2381.
11. [11]
  For the preparation, see: (a) Ma, C.; Liu, X.; Li, X.; Flippen-Anderson, J.; Yu, S.; Cook, J. M. J. Org. Chem. 2001, 66, 4525.(b) Zhou, H.; Liao, X.; Yin, W.; Ma, J.; Cook, J. M. J. Org. Chem. 2006, 71, 251.
12. [12]
  For reviews, see: Repka, L. M.; Reisman, S. E. J. Org. Chem. 2013, 78, 12314. For selected examples, see:(b) Savige, W. E. Aust. J. Chem. 1975, 28, 2275.(c) Nakagawa, M.; Hino, T. Heterocycles 1977, 6, 1675.(d) Nakagawa, M.; Kato, S.; Kataoka, S.; Hino, T. J. Am. Chem. Soc. 1979, 101, 3136.(e) Movassaghi, M.; Schmidt, M. A. Angew. Chem., Int. Ed. 2007, 46, 3725.(f) Furst, L.; Narayanam, J. M. R.; Stephenson, C. R. J. Angew. Chem., Int. Ed. 2011, 50, 9655.(g) Kim, J.; Movassaghi, M. J. Am. Chem. Soc. 2011, 133, 14940.(h) Sun, Y.; Li, R.; Zhang, W.; Li, A. Angew. Chem., Int. Ed. 2013, 52, 9201.
13. [13]
  CCDC 1445009 (6a') contains the supplementary crystallographic data for this paper. These data can be obtained free of charge from The Cambridge Crystallographic Data Centre via www.ccdc.cam. ac.uk/data_request/cif.
14. [14]
  For selected examples, see: (a) Schkeryantz, J. M.; Woo, J. C. G.; Danishefsky, S. J. J. Am. Chem. Soc. 1995, 117, 7025.(b) Schkeryantz, J. M.; Woo, J. C. G.; Siliphaivanh, P.; Depew, K. M.; Danishefsky, S. J. J. Am. Chem. Soc. 1999, 121, 11964.(c) Zhao, L.; May, J. P.; Huang, J.; Perrin, D. M. Org. Lett. 2012, 14, 90.
15. [15]
  Boto, A.; HernÁndez, R.; SuÁrez, E. Tetrahedron Lett. 1999, 40, 5945.(b) Boto, A.; HernÁndez, R.; SuÁrez, E. Tetrahedron Lett. 2000, 41, 2495.(c) Boto, A.; HernÁndez, R.; SuÁrez, E. J. Org. Chem. 2000, 65, 4930.
16. [16]
  See SI for the detailed characterization of compound 16.
17. [17]
  Evans, D. A.; Fu, G. C.; Hoveyda, A. H. J. Am. Chem. Soc. 1988, 110, 6917.(b) Burgess, K.; van der Donk, W. A.; Westcott, S. A.; Marder, T. B.; Baker, R. T.; Calabrese, J. C. J. Am. Chem. Soc. 1992, 114, 9350.
