High Efficiency Ternary Polymer Solar Cells Fabricated by Spray Coating

ZHANG Tong ^a,b ,
OUYANG Jinyang ^a,b ,
ZHAO Xiaoli ^a,b ,
YANG Xiaoniu ^a,b,,

a.
State Key Laboratory of Polymer Physics and Chemistry, Changchun Institute of Applied Chemistry, Chinese Academy of Sciences, Changchun 130022, China
b.
Polymer Composites Engineering Laboratory, Changchun Institute of Applied Chemistry, Chinese Academy of Sciences, Changchun 130022, China

Corresponding author: YANG Xiaoniu, xnyang@ciac.ac.cn
Received Date: 1 November 2019
Revised Date: 21 November 2019
Accepted Date: 22 November 2019

Fund Project: the National Natural Science Foundation of China 21574132the National Natural Science Foundation of China 21504090Supported by the National Natural Science Foundation of China(No.21574132, No.21504090)

Figures(6)

Non-fullerene small molecule acceptor (ITIC) is introduced into the binary polymer solar cells (PBTIBDTT:PCBM[70]) to build ternary polymer solar cells, which achieves power conversion efficiency (PCE) of 10.95% with more than 200 nm thickness of photoactive layers. The ternary polymer solar cells are further fabricated by spray coating method, and realize 9.06% of PCE. The high efficiency ternary polymer solar cells fabricated by spray coating are suitable for the roll-to-roll printing, exhibiting great application prospects.
- ternary polymer solar cells,
- non-fullerene small molecule acceptor,
- thick-film photoactive layer,
- spray coating,
- roll-to-roll printing
