Citation: LEI Xiaomei, LUO Faliang, SHEN Zhiyuan, SI Pengfei. Effects of 4, 4'-Thiobisphenol on the Crysatllization and Melting Behavior of Polyoxymethylene[J]. Chinese Journal of Applied Chemistry, ;2017, 34(2): 180-186. doi: 10.11944/j.issn.1000-0518.2017.02.160193 shu

Effects of 4, 4'-Thiobisphenol on the Crysatllization and Melting Behavior of Polyoxymethylene

LEI Xiaomei ^a,b ,
LUO Faliang ^a,*,, ,
SHEN Zhiyuan ^a ,
SI Pengfei ^a

a.
Ministry-Province Co-cultivated Key Laboratory Base of Natural Gas Conversion, Ningxia University, Yinchuan, 750021, China
b.
School of Chemistry and Chemical Engineering of Ningxia University, Yinchuan 750021, China

Corresponding author: LUO Faliang, flluo@iccas.ac.cn; flluo@iccas.ac.cn
Received Date: 10 May 2016
Revised Date: 15 June 2016
Accepted Date: 9 June 2016

Fund Project: the National Natural Science Foundation of China 21264012

Figures(6)

In order to explore the melting and crystallization behaviors of polyoxymethylene (POM) with the addition of 4, 4'-thiobisphenol (TDP), a series of POM/TDP alloys was prepared by melt blending of POM and TDP. The melting, crystallization behavior and crystal structure were studied by differential scanning calorimeter (DSC) and wide-angle X-ray diffraction (WAXD). The results demonstrate that POM has a less compact crystal structure with addition of TDP, which makes the melt crystallization temperatures (T_c), heat of crystallization (ΔH_c), melting temperatures (T_m) and heat of fusion (ΔH_m) decrease with the increase of the content of TDP. Incorporation of TDP with a mass fraction of 30% leads to reduction of melting point and crystallization temperature by 15.2℃ and 12.8℃ compared with pure POM, respectively. Meanwhile, it is worth noting that the crystallization time of POM increases with the increase of the content of TDP, the crystallization rate decreases, and crystallization activation energy increases gradually during isothermal crystallization process. The addition of TDP does not influence the crystal structure of POM, but has a great influence on the crystallization and melting behaviors of POM.
- polyoxymethylene,
- thiobisphenol,
- melt blending,
- melting,
- crystallization
1. [1]
  Pielichowska K, Dryzek E, Olejniczak Z. A Study on the Melting and Crystallization of Polyoxymethylene-copolymer/hydroxyapatite Nanocomposites[J]. Polym Adv Technol, 2013,24(3):318-330. doi: 10.1002/pat.v24.3
2. [2]
  Sun T, Lai Y, Ye L. A New and Highly Efficient Formaldehyde Absorbent of Polyoxymethylene[J]. Polym Adv Technol, 2008,19(9):1286-1295. doi: 10.1002/pat.v19:9
3. [3]
  Bai S, Wang Q. Effect of Injection Speed on Phase Morphology, Crystallization Behavior, and Mechanical Properties of Polyoxymethylene/poly (ethylene oxide) Crystalline/crystalline Blend in Injection Processing[J]. Polym Eng Sci, 2012,52(9):1938-1944. doi: 10.1002/pen.v52.9
4. [4]
  HONG Chenghai, WANG Xiaodong, LIU Dinan. Study on Toughen POM[J]. J Yanbian Univ, 2002,28(1):67-71.
5. [5]
  WANG Xiaodong, ZHANG Qiang. Studies on Miscibility of Polyacetal with Novolak[J]. Chem J Chinese Univ, 2001,22(4):669-672.
6. [6]
  LIU Pengbo, XU Wen, ZHANG Mingjun. Effect of Nucleator on the Crystallizing and Mechanical Properties of Polyoxymethylene[J]. Polym Mater Sci Eng, 2004,20(5):147-150.
7. [7]
  YU Jian. The Preparation, Characteristics and Application of Polyacetal[J]. Eng Plast Appl, 2001,29(3):41-44.
8. [8]
  JIN Lu, HE Yuan, LIU Baoying. Research Progress on Compatiblizing Modification of Toughened POM[J]. Plast Sci Technol, 2015,43(7):105-109.
9. [9]
  ZOU Hua, ZHAO Suhe. Research Advances in Blending Modification of POM[J]. Mod Plast Process Appl, 2000,12(4):54-57.
10. [10]
  DING Jun, LIU Weimin, PAN Guangqin. Toughening Behavior of Polyoxymethylene Blends with Different Therm Oplastic Elastomers[J]. China Synth Rubber Ind, 2005,28(3):195-199.
11. [11]
  BAI Shibing, LIU Jinglin, WANG Qi. Effect of PEO on Nonisothermal Crystallization of POM in POM/PEO Blends[J]. Polym Mater Sci Eng, 2007,23(6):136-139.
12. [12]
  SI Pengfei, LUO Faliang, HAI Mei. Intermolecular Interactions and Crystallization and Melting Behavior of Poly (L-lactic acid)/4, 4'-Thiobis Phenol Blends[J]. Chem J Chinese Univ, 2015,36(1):188-194.
13. [13]
  JIN Riguang, HUA Youqing. Textbook of Polymer Physics[M]. 3nd Ed. Beijing:Chemical Industry Press, 2006:156-157(in Chinese).
14. [14]
  GAO Guanghui, LI Weihua, YAN Deyue. Investigation on Crystallization Kinetics of Nylon 1218[J]. Acta Polym Sin, 2004(4):465-470.
15. [15]
  Avrami M. Kinetics of Phase Change.I.General Theory[J]. J Chem Phys, 19329,7(12):1103-1119.
16. [16]
  Avrami M. Kinetics of Phase Change.Ⅱ.Transformation-time Relations for Random Distribution of Nuclei[J]. J Chem Phys, 1940,8(2):212-220. doi: 10.1063/1.1750631
17. [17]
  HOU Shaohua, WU Sizhu, WU Gang. Study on Isothermal Crystallization Kinetics of a New Polyester-PMT[J]. New Chem Mater, 2004,32(10):37-40.
18. [18]
  YU Xiang, ZHU Chengshen, HE Suqin. Avrami Kinetics Study of the Isothermal Crystallization of Poly (ε-caprolactone)[J]. Mater Rev, 2010,24(20):108-112.
19. [19]
  Cebe P, Hong S D. Crystallization Behavior of Poly (etheretherketone)[J]. Polymer, 1986,27(8):1183-1192. doi: 10.1016/0032-3861(86)90006-6
20. [20]
  Guo L, Xu X, Zhang Y. Effect of Functionalized Nanosilica on Properties of Polyoxymethylene-matrix Nanocomposites[J]. Polym Compos, 2014,35(1):127-136. doi: 10.1002/pc.v35.1
