Citation: Qu ZHANG, Tao WANG, Yinying WANG, Bo LI, Dongling WU. Synthesis of amino acid-functionalized nitrogen-doped carbon dots/cuprous oxidecomposite material and its performance in aqueous zinc-ion batteries[J]. Chinese Journal of Inorganic Chemistry, ;2026, 42(3): 488-498. doi: 10.11862/CJIC.20250272 shu

Synthesis of amino acid-functionalized nitrogen-doped carbon dots/cuprous oxidecomposite material and its performance in aqueous zinc-ion batteries

Qu ZHANG ¹ ,
Tao WANG ² ,
Yinying WANG ¹ ,
Bo LI ¹ ,
Dongling WU ^1,,

1.
State Key Laboratory of Chemistry and Utilization of Carbon Based Energy Resources, College of Chemistry, Xinjiang University, Urumqi 830017, China
2.
Xinjiang Engineering Research Center of Environmental and Functional Materials, School of Materials Science and Engineering, Xinjiang University, Urumqi 830017, China

Corresponding author: Dongling WU, wudl@xju.edu.cn
Received Date: 28 August 2025
Revised Date: 7 December 2025

Figures(6)

In this work, a 3D hierarchical nitrogen-doped carbon quantum dots/cuprous oxide (N-CDs/Cu₂O) nanocomposite was successfully fabricated through an amino acid-mediated self-assembly approach. The Cu₂O, formed under the guidance of amino acids with distinct acidities, exhibited varying sizes and crystallinities. The 3D hierarchical structure, formed upon integration with N-CDs, endowed the material with an abundant porous network, thus effectively promoting electrolyte infiltration. Moreover, N-CDs accelerated ion/electron transport through defect engineering and interface optimization. Additionally, the robust heterointerfaces established by N-CDs constrained volume expansion during the charge-discharge process. Notably, the glycine-assisted synthesized N-CDs/Cu₂O composite electrode demonstrated an impressive initial discharge capacity of 373 mAh·g^-1 at a current density of 0.1 A·g^-1, and retained 78% of its capacity after 100 cycles.
- amino acids,
- Cu₂O,
- N-doped carbon quantum dots,
- cathode materials,
- aqueous zinc-ion batteries
1. [1]
  CHEN X J, LI W, REED D, LI X L, LIU X B. On energy storage chemistry of aqueous Zn-ion batteries: From cathode to anode[J]. Electrochem. Energy Rev., 2023,6(1):33-121. doi: 10.1007/s41918-023-00194-6
2. [2]
  JIANG L, DING Y Q, LI L, TANG Y, ZHOU P, LU B G, TIAN S Y, ZHOU J. Cationic adsorption-induced microlevelling effect: A pathway to dendrite-free zinc anodes[J]. Nano‒Micro Lett., 2025,17(1):202-214.
3. [3]
  CHEN M J, GONG Y X, ZHAO Y X, SONG Y X, TANG Y, ZENG Z Y, LIANG S Q, ZHOU P, LU B G, ZHANG X T, ZHOU J. Spontaneous grain refinement effect of rare earth zinc alloy anodes enables stable zinc batteries[J]. Natl. Sci. Rev., 2024,11(7)nwae205. doi: 10.1093/nsr/nwae205
4. [4]
  LI Y, WANG Z H, CAI Y, PAM M E, YANG Y K, ZHANG D H, WANG Y, HUANG S Z. Designing advanced aqueous zinc-ion batteries: Principles, strategies, and perspectives[J]. Energy Environ. Mater., 2022,5(3):823-851. doi: 10.1002/eem2.12265
5. [5]
  LI W, WANG D H. Conversion-type cathode materials for aqueous Zn metal batteries in nonalkaline aqueous electrolytes: Progress, challenges, and solutions[J]. Adv. Mater., 2023,37(31)2304983.
6. [6]
  CAO Y N, JU S D, ZHANG Q, GAO K, AUGUSO M, ZHANG Z P. Recent progress in aqueous zinc-ion batteries based on conversion-type cathodes[J]. Adv. Powder Mater., 2025,4(2)100278. doi: 10.1016/j.apmate.2025.100278
7. [7]
  MENG J L, YANG Z H, CHEN L L, ZENG X, CHEN H Z, CUI F, JIANG Y N. The investigation on the electrochemical performance of CuI as cathode material for zinc storage[J]. Electrochim. Acta, 2020,338135915. doi: 10.1016/j.electacta.2020.135915
8. [8]
  WANG Y C, WANG B Y, ZHANG J S, CHAO D L, NI J F, LI L. Conversion electrochemistry of copper selenides for robust and energetic aqueous batteries[J]. Carbon Energy, 2022,5(2):261-270.
9. [9]
  MENG J L, YANG Z H, CHEN L L, QIN H G, CUI F, JIANG Y N, ZENG X. Energy storage performance of CuO as a cathode material for aqueous zinc ion battery[J]. Mater. Today Energy, 2020,15100370. doi: 10.1016/j.mtener.2019.100370
10. [10]
  AI Y P, PANG Q, LIU X Y, XIN F Y, WANG H, XING M M, FU Y, TIAN Y. Porous CuO microspheres as long-lifespan cathode materials for aqueous zinc-ion batteries[J]. Nanomaterials, 2024,14(13):1145-1155. doi: 10.3390/nano14131145
11. [11]
  XU H T, YANG W Y, LI M, LIU H B, GONG S Q, ZHAO F, LI C L, QI J J, WANG H H, PENG W C, LIU J P. Advances in aqueous zinc ion batteries based on conversion mechanism: challenges, strategies, and prospects[J]. Small, 2023,20(27)2310972.
12. [12]
  FAN Y L, WANG Q P, XIE Y Y, ZHOU N G, YANG Y, DING Y C, WEI Y, QIU G Y. Advances in aqueous zinc-ion battery systems: Cathode materials and chemistry[J]. Prog. Mater Sci., 2025,149101393. doi: 10.1016/j.pmatsci.2024.101393
13. [13]
  FAN Z Y, WANG J W, WU YP, YAN X D, DAI D M, WU X Y. Research progresses on cathode materials of aqueous zinc-ion batteries[J]. J. Energy Chem., 2024,97:237-264. doi: 10.1016/j.jechem.2024.05.033
14. [14]
  ZOU Q L, YAN X H. Amino acid coordinated self-assembly[J]. Chem. Eur. J., 2018,24(4):755-761. doi: 10.1002/chem.201704032
15. [15]
  HOU H Y, LAN J, YAO Y, XU J L, FENG M M. Li-storage performances of flower-like CuO/ZnO nanoparticles derived from bimetallic CuZn-L-phenylalanine precursor[J]. Ionics, 2021,27(4):1589-1595. doi: 10.1007/s11581-020-03877-y
16. [16]
  KUMAR P V, INGOLE P P. Altering the electrocatalytic activity of plasmonic Cu/Cu₂O nanocomposites towards water splitting through surface functionalization with various amino acids[J]. ChemistrySelect, 2020,5(23):7049-7055. doi: 10.1002/slct.202001062
17. [17]
  DEDONG Z, MAIMAITI H, AWATI A, YISILAMU G, FENGCHANG S, MING W. Synthesis and photocatalytic CO₂ reduction performance of Cu₂O/coal-based carbon nanoparticle composites[J]. Chem. Phys. Lett., 2018,700:27-35. doi: 10.1016/j.cplett.2018.04.007
18. [18]
  WANG T, REN P X, LIU Q, ZHANG Q, ZHENG Y F, JIA D Z. Coal tar pitch-based porous carbon: Synthetic strategies and their applications in energy storage[J]. Adv. Funct. Mater., 2025,36e04092. doi: 10.1002/adfm.202504092
19. [19]
  KUMAR V B, MIRSKY S K, SHAKED N T, GAZIT E. High quantum yield amino acid carbon quantum dots with unparalleled refractive index[J]. ACS Nano, 2024,18(3):2421-2433. doi: 10.1021/acsnano.3c10792
20. [20]
  MA Q L, SONG T B, HE T L, ZHANG X R, XIONG H M. Sulfur-doped carbon dots: A novel bifunctional electrolyte additive for high-performance aqueous zinc-ion batteries[J]. Acta Phys. ‒Chim. Sin., 2025,41(9)100106.
21. [21]
  KIM J, JANG W, KIM J H, YANG C M. Synthesis of graphene quantum dots-coated hierarchical CuO microspheres composite for use as binder-free anode for lithium-ion batteries[J]. Compos. Pt. B‒Eng., 2021,222109083. doi: 10.1016/j.compositesb.2021.109083
22. [22]
  ZHANG Q, LIU P G, WANG T, LIU Q, WU D L. Core-shell structures of Cu₂O constructed by carbon quantum dots as high‑ performance zinc-ion battery cathodes[J]. J. Mater. Chem. A, 2023,11(45):24823-24835. doi: 10.1039/D3TA05705D
23. [23]
  CHEN C, YAN D, VON LIM Y, LIU L, LI X L, CHEN J J, LI T C, ZHU Y Y, CAI J T, HUANG Y, ZHANG Y T, YANG H Y. Flame-assisted ultrafast synthesis of functionalized carbon nanosheets for high-performance sodium storage[J]. Carbon Energy, 2024,6(7)e482. doi: 10.1002/cey2.482
24. [24]
  REN P X, WEN H L, WANG T, ZHENG Y F, SHENG R, WU D L. Metal salt modulation strategy to prepare highly defective coal-based porous carbon for solid-state zinc ion hybrid capacitors[J]. Chem. Eng. J., 2025,522167842. doi: 10.1016/j.cej.2025.167842
25. [25]
  HUANG P F, GUO Z X, LI Z K, CHEN L, LIU W D, LUO J W, LIU Z D, ZHANG J C, ZENG J R, ZHANG W J, ZHANG X X, ZHU R T, CHEN Y N. Spatiotemporal evolution in hard carbon synthesis via electrothermal coupling strategy for high-performance sodium-ion batteries[J]. Adv. Mater., 2025,37(38)2507521. doi: 10.1002/adma.202507521
26. [26]
  ISMAEL F, MEHDI G, SPIROS P, STEOHEN F, PAVEL N A. Data requirements for the determination of a sub-centimeter geoid[J]. Earth Sci. Rev., 2023,239104326. doi: 10.1016/j.earscirev.2023.104326
27. [27]
  XIONG T, ZHANG Y X, LEE W S V. Defective engineering as a promising strategy for advanced aqueous Zn ion batteries[J]. ACS Energy Lett., 2025,10(7):3287-3305. doi: 10.1021/acsenergylett.5c00960
28. [28]
  WANG T, WU D L, YUAN F, LIU Q, LI W Y, JIA D Z. Chitosan derived porous carbon prepared by amino acid proton salt for high-performance quasi-state-solid supercapacitor[J]. Chem. Eng. J., 2023,462142292. doi: 10.1016/j.cej.2023.142292
29. [29]
  REN P X, WU D L, WANG T, ZENG P, JIA D Z. K₂CO₃-KCl Acts as a molten salt flame retardant to prepare N and O doped honeycomb-like carbon in air for supercapacitors[J]. J. Power Sources, 2022,532231072. doi: 10.1016/j.jpowsour.2022.231072
30. [30]
  CHEN B L, WU D L, WANG T, YUAN F, JIA D Z. Rapid preparation of porous carbon by flame burning carbonization method for supercapacitor[J]. Chem. Eng. J., 2023,462142163. doi: 10.1016/j.cej.2023.142163
31. [31]
  LIU Q, WU D L, WANG T, WANG C G, JIA D Z. Pre-oxidating and pre-carbonizing to regulate the composition and structure of coal tar pitch: The fabrication of porous carbon for supercapacitor applications[J]. Adv. Funct. Mater., 2024,34(29)202400556.
32. [32]
  ZHENG Y F, WU D L, WANG T, LIU Q, JIA D Z. Advanced eutectogel electrolyte for high-performance and wide-temperature flexible zinc‑air batteries[J]. Angew. Chem. ‒Int. Edit., 2025,64(6)e202418223. doi: 10.1002/anie.202418223
33. [33]
  THOMAS S A, PALLAVOLU M R, KHAN M E, CHERUSSERI J. Graphitic carbon nitride (g-C₃N₄): Futuristic material for rechargeable batteries[J]. J. Energy Storage, 2023,68107673. doi: 10.1016/j.est.2023.107673
34. [34]
  YANG Y T, TANG Z J, BIAN S Y, GU Y L, YE F, CHEN W S, ZHU K J, WU Y P, HU L F. Zinc ion transport kinetics in zinc-based batteries and its regulation strategy[J]. Adv. Energy Mater., 2025,15(38)2500316. doi: 10.1002/aenm.202500316
35. [35]
  QIN D D, DING J Y, LIANG C, LIU Q, FENG L G, LUO Y, HU G Z, LUO J, LIU X J. Addressing challenges and enhancing performance of manganese-based cathode materials in aqueous zinc-ion batteries[J]. Acta Phys. ‒Chim. Sin., 2024,40(10)2310034.
36. [36]
  GAO P, METZ P, HEY T, GONG Y X, LIU D W, EDWARDES D D, HOWE J Y, HUANG R, MISTURE S T. The critical role of point defects in improving the specific capacitance of δ-MnO₂ nanosheets[J]. Nat. Commun., 2017,8(1):14559-14568. doi: 10.1038/ncomms14559
