Citation: Shoutao LIU, Jianwei ZHAO, Fenying WANG, Hanjie MA. Relationship between the tensile fracture distribution of the hollow copper nanowires and the initial slip distribution[J]. Chinese Journal of Inorganic Chemistry, ;2024, 40(2): 394-404. doi: 10.11862/CJIC.20230171 shu

Relationship between the tensile fracture distribution of the hollow copper nanowires and the initial slip distribution

1.
College of Information Science and Engineering, Zhejiang Sci-Tech University, Hangzhou 310018, China
2.
College of Material and Textile Engineering, Jiaxing University, Jiaxing, Zhejiang 314001, China
3.
College of Chemistry and Chemical Engineering, Nanchang University, Nanchang 330031, China
4.
College of Computer Science and Technology (School of Artificial Intelligence), Zhejiang Sci-Tech University, Hangzhou 310018, China

Corresponding author: Jianwei ZHAO, jwzhao@zjxu.edu.cn
Received Date: 9 May 2023
Revised Date: 2 January 2024

Figures(9)

To investigate the relationship between the fracture failure and the initial microstructure of the hollow nanowires (NW), a series of spherical hollow structures were constructed and molecular dynamics (MD) simulations were performed with 300 samples that have different initial states. The position of the initial slip plane was obtained using the density-based spatial clustering of applications with noise (DBSCAN) machine learning algorithm. Based on big data analysis, the distribution of the initial slip position and the fracture position were analyzed. The result of the correlation between the two shows that when the inner hollow radius is small, the distribution of fracture posi- tions is formed during the plastic deformation stage, so there is no correlation between the distribution of initial slip and fracture positions. However, for brittle NW with significantly larger hollow radii, the slip plane induced by the high -energy inner surface quickly accumulates, resulting in necking and ultimately fracture. Therefore, when the internal hollow structure reaches a certain size, there is a clear causal relationship between the distribution of initial slip positions and the distribution of final fracture positions.
