Citation: Jian-Feng LIAO, Lin SUN, Ruo-Yu CHEN, Jing-Ya DING. Facile synthesis of high nitrogen doped porous carbon nanofibers for high performance sodium ion capacitor[J]. Chinese Journal of Inorganic Chemistry, ;2023, 39(7): 1349-1359. doi: 10.11862/CJIC.2023.086 shu

Facile synthesis of high nitrogen doped porous carbon nanofibers for high performance sodium ion capacitor

Jian-Feng LIAO ^{1, 2} ,
Lin SUN ^{1, 2, 3,,} ,
Ruo-Yu CHEN ^1,, ,
Jing-Ya DING ^2,,

1.
School of Petrochemical Engineering, Changzhou University, Changzhou, Jiangsu 213164, China
2.
Key Laboratory for Advanced Technology in Environmental Protection of Jiangsu Province, School of Chemistry and Chemical Engineering, Yancheng Institute of Technology, Yancheng, Jiangsu 224051, China
3.
State Key Laboratory of Coordination Chemistry, Nanjing University, Nanjing 210023, China

Corresponding author: Lin SUN, sunlin@nju.edu.cn Ruo-Yu CHEN, chry@cczu.edu.cn Jing-Ya DING, 18261276398@163.com
Received Date: 21 February 2023
Revised Date: 27 April 2023

Figures(7)

One of the effective approaches to obtaining functional carbon materials is selecting some appropriate biomass materials. In this work, the high nitrogen-doped porous carbon nanofibers (NPCF) can be obtained by one-step pyrolysis of potassium citrate and melamine. The NPCF electrode delivered capacities of 218 and 140 mAh·g^-1 at current densities of 0.1 and 1.0 A·g^-1, respectively. Concurrently, the sodium ion capacitors (SICs) with NPCF anode show outstanding rate performance and long lifespan for over 2 500 cycles at 1.0 A·g^-1.
- biomass carbon material,
- anode material,
- sodium ion capacitor
