Citation: Xue-Bing YANG, Xiao-Na HU, Xu SUN. Effect of Acetylene Black Coating on Properties of Lithium-Sulfur Batteries[J]. Chinese Journal of Inorganic Chemistry, ;2021, 37(12): 2203-2208. doi: 10.11862/CJIC.2021.248 shu

Effect of Acetylene Black Coating on Properties of Lithium-Sulfur Batteries

Institute of Applied Physics, Jiangxi Academy of Science, Nanchang 330096, China

Corresponding author: Xue-Bing YANG, xbyjz@163.com
Received Date: 18 June 2021
Revised Date: 11 October 2021

Figures(8)

Cyclic discharge stability of lithium-sulfur batteries is relatively low. Herein, a method of low cost has been adopted to improve properties of lithium-sulfur batteries. A coating of acetylene black has been prepared on the surface of sulfur electrodes. The morphology of materials and properties for batteries have been tested. The results indicate that the sulfur adheres to the surface of acetylene black particles in sulfur-acetylene black composite with sulfur content (mass fraction) of 70%. The acetylene black coating with thickness of about 15 μm has been prepared on the surface of lithium electrodes. The voltage for oxidation reaction of sulfur electrodes with acetylene black coating was lower than that of sulfur electrodes. Acetylene black coating is helpful in oxidation reaction of sulfur electrodes. The aggregation degree of active materials for sulfur electrodes with acetylene black coating was lower than that for sulfur electrodes. The discharge specific capacity and cyclic discharge stability of sulfur electrodes with acetylene black coating were higher than those of sulfur electrodes. After 150 cycles of charge and discharge, the discharge specific capacity of sulfur electrodes with acetylene black coating was 894 mAh·g^-1.
- lithium-sulfur batteries,
- sulfur electrode,
- acetylene black,
- cycle properties
1. [1]
  Hou Y Z, Ren Y B, Zhang S C, Wang K P. 3D S@MoS₂@Reduced Grapheme Oxide Aerogels Cathode for High-Rate Lithium-Sulfur Batteries[J]. J. Alloys Compd., 2021,852157011. doi: 10.1016/j.jallcom.2020.157011
2. [2]
  Xi Y K, Natarajan A, Zhang B Y, Tian X H. A Co₉S₈ Microsphere and N-Doped Carbon Nanotube Composite Host Material for Lithium-Sulfur Batteries[J]. J. Alloys Compd., 2020,826154201. doi: 10.1016/j.jallcom.2020.154201
3. [3]
  Liu F, Sun G, Wu H B, Chen G, Xu D, Mo R W, Shen L, Li X Y, Ma S X, Tao R, Li X R, Tan X Y, Xu B, Wang G, Dunn B S, Sautet P, Lu Y F. Dual Redox Mediators Accelerate the ELectrochemical Kinetics of Lithium-Sulfur Batteries[J]. Nat. Commun., 2020,115215. doi: 10.1038/s41467-020-19070-8
4. [4]
  Liu L, Yang F, Ge L, Liu C H. Facile Preparation of Nitrogen-Doped Hierarchical Porous Carbon as a Sulfur Cathode Host for High Performance Lithium-Sulfur Batteries[J]. Microporous Mesoporous Mater., 2021,312110749. doi: 10.1016/j.micromeso.2020.110749
5. [5]
  Hou J H, Tu X Y, Wu X G, Shen M. Remarkable Cycling Durability of Lithium-Sulfur Batteries with Interconnected Mesoporous Hollow Carbon Nanospheres as High Sulfur Content Host[J]. Chem. Eng. J., 2020,401126141. doi: 10.1016/j.cej.2020.126141
6. [6]
  Gao X G, Huang Y, Gao H, Batool S. Sulfur Double Encapsulated in a Porous Hollow Carbon Aerogel with Interconnected Micropores for Advanced Lithium-Sulfur Batteries[J]. J. Alloys Compd., 2020,834155190. doi: 10.1016/j.jallcom.2020.155190
7. [7]
  Zhang X Y, Zhou H Y, Wang J G. Nitrogen-Rich Microporous Carbon Framework as an Efficient Polysulfide Host for Lithium-Sulfur Batteries[J]. J. Mater. Sci., 2021,56:3364-3374. doi: 10.1007/s10853-020-05433-5
8. [8]
  Zhang X Q, Yuan W, Yang Y, Yang S Z, Wang C, Yuan Y H, Wu Y P, Kang W Q, Tang Y. Green and Facile Fabrication of Porous Titanium Dioxide as Efficient Sulfur Host for Advanced Lithium-Sulfur Batteries: An Air oxidation Strategy[J]. J. Colloid Interface Sci., 2021,583:157-165. doi: 10.1016/j.jcis.2020.09.020
9. [9]
  Jin Z S, Liang Z M, Zhao M, Zhang Q, Liu B Q, Zhang L Y, Chen L H, Li L, Wang C G. Rational Design of MoNi Sulfide Yolk-Shell Heterostructure Nanospheres as the Efficient Sulfur Hosts for High-Performance Lithium-Sulfur Batteries[J]. Chem. Eng. J., 2020,394124983. doi: 10.1016/j.cej.2020.124983
10. [10]
  LI R, SUN X G, ZOU J Y, HE Q. NMAP Interlayer for Inhibiting Shuttle Effect of Lithium-Sulfur Battery[J]. Chinese J. Inorg. Chem., 2020,36(4):673-680.
11. [11]
  PAN P F, CHEN P, FANG Y N, SHAN Q, CHEN N N, FENG X M, LIU R Q, LI P, MA Y W. V₂O₅ Hollow Sphere as High Efficient Sulfur Host for Li-S Batteries[J]. Chinese J. Inorg. Chem., 2020,36(3):575-583.
