Citation: ZHOU Xin, ZHANG Mei-Na, ZHANG De-Chun, LI Xia, YAO Ying-Fang. Syntheses, Crystal Structures and Fluorescence Sensing of Lanthanide Complexes with 3, 4'-Biphenyldicarboxylic Acid and N-donor Ligands[J]. Chinese Journal of Inorganic Chemistry, ;2018, 34(7): 1285-1292. doi: 10.11862/CJIC.2018.153 shu

Syntheses, Crystal Structures and Fluorescence Sensing of Lanthanide Complexes with 3, 4'-Biphenyldicarboxylic Acid and N-donor Ligands

Department of Chemistry, Capital Normal University, Beijing 100048, China

Corresponding author: LI Xia, xiali@mail.cnu.edu.cn
Received Date: 25 January 2018
Revised Date: 2 April 2018

Figures(6)

Two lanthanide complexes, [Gd(3, 4'-dpdc)₂(HDPP)]_n (1) and {[Dy(3, 4'-Hdpdc)₃(H₂O)]·0.5BTB}_n (2) (3, 4'-H₂dpdc=3, 4'-biphenyldicarboxylic acid, DPP=1, 3-bis(4-pyridyl)propane, BTB=1, 4-bis(1, 2, 4-triazol-1-yl)butane) were successfully synthesized under hydrothermal reactions, and their structures were characterized by single crystal X-ray diffraction. Complex 1 belongs to monoclinic system, space group P2₁/c. It is two-dimensional layered structure and consists of[GdO₇N] unit. 3, 4'-dpdc ligands are connected to the Gd(Ⅲ) ions by μ₁:η¹η¹/μ₂:η¹η¹ and μ₁:η¹η¹/μ₁:η¹η⁰ coordination modes. DPP ligands are end-coordinated to Gd(Ⅲ) ions. Complex 2 is a triclinic system, space group P1. The complex shows a one-dimensional chain structure. The coordination environment of Dy(Ⅲ) ion is[DyO₇]. The 3, 4'-Hdpdc ligands link Dy(Ⅲ) ions in a μ₂:η¹η¹ coordination mode. The BTB molecules are connected to the one-dimensional chains by hydrogen bonds and thus form a three-dimensional supramolecular structure. Solid state photoluminescence measurements show that compounds 1 and 2 display broad band in the range of 350~650 nm due to the π^*→π transition of the ligands. The effect of different floxacins on the luminescence of complex 1 in aqueous solution was studied. The results showed that the complex could identify pefloxacin.
- lanthanide complex,
- 3, 4'-biphenyldicarboxylic acid,
- crystal structure,
- fluorescence
1. [1]
  Park K H, Jang K, Son S U, et al. J. Am. Chem. Soc., 2006, 128(27):8740-8741 doi: 10.1021/ja062907o
2. [2]
  Farrusseng D, Aguado S, Pinel C. Angew. Chem. Int. Ed., 2009, 48(41):7502-7513 doi: 10.1002/anie.v48:41
3. [3]
  Zheng M, Tan H Q, Xie Z G, et al. ACS Appl. Mater. Interfaces, 2013, 5(3):1078-1083 doi: 10.1021/am302862k
4. [4]
  Chen B L, Xiang S C, Qian G D. Acc. Chem. Res., 2010, 43(8):1115-1124 doi: 10.1021/ar100023y
5. [5]
  Lee J Y, Olson D H, Pan L, et al. Adv. Funct. Mater., 2007, 17(8):1255-1262 doi: 10.1002/(ISSN)1616-3028
6. [6]
  Li J R, Kuppler R J, Zhou H C. Chem. Soc. Rev., 2009, 38(5):1477-1504 doi: 10.1039/b802426j
7. [7]
  Taylor K M L, Jin A, Lin W B. Angew. Chem. Int. Ed., 2008, 47(40):7722-7725 doi: 10.1002/anie.v47:40
8. [8]
  Liu D M, Huxford R C, Lin W B. Angew. Chem. Int. Ed., 2011, 50(16):3696-3700 doi: 10.1002/anie.v50.16
9. [9]
  Imaz I, Rubio-Martinez M. Garcia-Fernandez L, et al. Chem. Commun., 2010, 46(26):4737-4739
10. [10]
  Gao P F, Zheng L L, Liang L J, et al. J. Mater. Chem. B, 2013, 1(25):3202-3208 doi: 10.1039/c3tb00026e
11. [11]
  Wu C, Kasipandi V, Yang G J, et al. Dalton Trans., 2017, 46(20):6677-6682 doi: 10.1039/C7DT00633K
12. [12]
  ZHANG Mei-Na, ZHENG Xiao-Li, LI Xia, et al. Chinese J. Inorg. Chem., 2017, 33(7):1172-1180 doi: 10.11862/CJIC.2017.137
13. [13]
  Yang W T, Feng J, Zhang H J. J. Mater. Chem., 2012, 22(14):68196823
14. [14]
  Wong K L, Law G L, Yang Y Y, et al. Adv. Mater., 2006, 18(8):1051-1054 doi: 10.1002/(ISSN)1521-4095
15. [15]
  Chen B L, Wang L B, Zapata F, et al. J. Am. Chem. Soc., 2008, 130(21):6718-6719 doi: 10.1021/ja802035e
16. [16]
  Chen B L, Yang Y, Zapata F, et al. Adv. Mater., 2007, 19(13):1693-1696 doi: 10.1002/(ISSN)1521-4095
17. [17]
  Xu H, Liu F, Cui Y J, et al. Chem. Commun., 2011, 47(11):3153-3155 doi: 10.1039/c0cc05166g
18. [18]
  Zhu P H, Wang Y C, Ma P, et al. Dalton Trans., 2017, 46(5):1531-1538 doi: 10.1039/C6DT04257K
19. [19]
  Xia Q H, Yang Y L, Liu M S. Spectrochim. Acta Part A, 2012, 96:358-364 doi: 10.1016/j.saa.2012.05.048
20. [20]
  Ni Y N, Su S J, Kokot S. Spectrochim. Acta Part A, 2010, 75:547-552 doi: 10.1016/j.saa.2009.11.014
21. [21]
  Della Rocca J, Liu D M, Lin W B. Acc. Chem. Res., 2011, 44(10):957-968 doi: 10.1021/ar200028a
22. [22]
  Richardson F S. Chem. Rev., 1982, 82(5):541-552 doi: 10.1021/cr00051a004
23. [23]
  Yang L R, Wu L Z, Zhang H M, et al. Dyes Pigm., 2013, 99(2):257-267 doi: 10.1016/j.dyepig.2013.05.004
24. [24]
  Zhang J, Chew E, Chen S M, et al. Inorg. Chem., 2008, 47(9):3495-3497 doi: 10.1021/ic800195u
25. [25]
  Malaestean I L, Speldrich M, Baca S G, et al. Eur. J. Inorg. Chem., 2009(8):1011-1018
26. [26]
  Yin P X, Zhang J, Li Z J, et al. Inorg. Chim. Acta, 2007, 360(11):3525-3532 doi: 10.1016/j.ica.2007.04.035
27. [27]
  Xu X X, Lu Y, Wang E B, et al. Cryst. Growth Des., 2006, 6(9):2029-2035 doi: 10.1021/cg050671e
28. [28]
  Xu X X, Liu X X, Zhang X, et al. Inorg. Chim. Acta, 2009, 362(15):5203-5210 doi: 10.1016/j.ica.2009.09.025
29. [29]
  GENG Xiao-Hong, FENG Yun-Long. Chinese J. Inorg. Chem., 2010, 26(2):360-364
30. [30]
  Li X, Gu Y K, Deng X B, et al. CrystEngComm, 2011, 13(22):6665-6673 doi: 10.1039/c1ce05491k
31. [31]
  Carlucci L, Ciani G, Proserpio D M, et al. CrystEngComm, 2002, 4:121-129 doi: 10.1039/b201288j
32. [32]
  Sheldrick G M. SHELXS-97, Program for Crystal Structure Refinement, University of Göttingen, Germany, 1997.
33. [33]
  Sheldrick G M. SHELXL-97, Program for Crystal Structure Solution, University of Göttingen, Germany, 1997.
