Citation: SHI Chang-Dong, CHEN Sheng, CHENG Mei-Ling, RONG Hong-Ren, LAI Li-Fang, LIU Wen-Long, LIU Qi. Syntheses, Structures, and Luminescent Properties of Cadium and Copper Complexes Containing Pyrazole Carboxylic Acid of Uncoordinated Carboxyl Group[J]. Chinese Journal of Inorganic Chemistry, ;2017, 33(1): 89-96. doi: 10.11862/CJIC.2016.278 shu

Syntheses, Structures, and Luminescent Properties of Cadium and Copper Complexes Containing Pyrazole Carboxylic Acid of Uncoordinated Carboxyl Group

SHI Chang-Dong ¹ ,
CHEN Sheng ¹ ,
CHENG Mei-Ling ¹ ,
RONG Hong-Ren ¹ ,
LAI Li-Fang ¹ ,
LIU Wen-Long ^2,*,, ,
LIU Qi ^1,3,*,,

1.
School of Petrochemical Engineering and Jiangsu Key Laboratory of Advanced Catalytic Materials and Technology, Changzhou University, Changzhou, Jiangsu 213164, China
2.
College of Chemistry and Chemical Engineering, Yangzhou University, Yangzhou, Jiangsu 225002, China
3.
State Key Laboratory of Coordination Chemistry, Nanjing University, Nanjing, Jiangsu 210093, China

Corresponding author: LIU Wen-Long, njulwl@163.com LIU Qi, liuqi62@163.com
Received Date: 31 July 2016
Revised Date: 20 October 2016

Figures(6)

Two new complexes[Cd(Hcmdpca)₂(phen)(H₂O)] (1) and [Cu₂(Hcmdpca)₂(phen)₄(NO₃)₂]·4H₂O (2) (H₂cmdpca=1-carboxymethyl-3,5-dimethyl-1H-pyrazole-4-carboxylic acid, phen=phenanthroline) have been synth-esized and characterized by IR spectra, elemental analysis, single crystal X-ray diffraction, thermogravimetric analysis. Complexes 1 and 2 all crystallize in the monoclinic system and their space group are C2/c and P2₁/c, respectively. In 1, Cd(Ⅱ) ion takes seven-coordination mode, and Hcmdpca- anion bridges adjacent Cd(Ⅱ) ions to generate a dinuclear structure; these dinuclear structure units are assembled into a 3D network via hydrogen bonds and π-π interactions. 2 is an independent unit consisted of two discrete mononuclear Cu(Ⅱ) complex cations, each Cu(Ⅱ) ion is located in a distorted octahedral geometry. These mononuclear Cu(Ⅱ) complex cations and NO₃^- ions are connected by electrostatic interactions and hydrogen bonds, producing a 3D supramolecular network, and the hollow space of the network are occupied by water molecules. The thermal stability and luminescent property of the complexes are also investigated. CCDC:1495594, 1; 1495595, 2.
- Cd(Ⅱ),
- Cu(Ⅱ),
- 1-Carboxymethyl-3,5-dimethyl-1H-pyrazole-4-carboxylic acid,
- crystal structure,
- photoluminescence,
1. [1]
  Ohara K, Kawano M, Inokuma Y, et al. J. Am. Chem. Soc., 2010,132(1):30-31 doi: 10.1021/ja908794n
2. [2]
  Yoon M, Srirambalaji R, Kim K, et al. Chem. Rev., 2012, 112(2):1196-1231 doi: 10.1021/cr2003147
3. [3]
  Furukawa H, Cordova K E, O'Keeffe M, et al. Science, 2013, 341(6149):1230444(12 pages) doi: 10.1126/science.1230444
4. [4]
  O'Keeffe M, Yaghi O M. Chem. Rev., 2012,112(2):675-702 doi: 10.1021/cr200205j
5. [5]
  Rosi N L, Eckert J, Eddaoudi M, et al. Science, 2003,300(5622):1127-1129 doi: 10.1126/science.1083440
6. [6]
  Choi H J, Dinc M, Long J R, et al. J. Am. Chem. Soc., 2008, 130(25):7848-7850 doi: 10.1021/ja8024092
7. [7]
  Kreno L E, Leong K, Farha O K, et al. Chem. Rev., 2012,112(2):1105-1125 doi: 10.1021/cr200324t
8. [8]
  Yang P, Wang M S, Shen J J, et al. Dalton Trans., 2014,43(3):1460-1470 doi: 10.1039/C3DT52500G
9. [9]
  Wang H Y, Wu Y, Leong C F, et al. Inorg. Chem., 2015,54(22):10766-10775 doi: 10.1021/acs.inorgchem.5b01803
10. [10]
  Férey G, Millange F, Morcrette M, et al. Angew. Chem. Int. Ed., 2007,46(18):3259-3263 doi: 10.1002/(ISSN)1521-3773
11. [11]
  Liu Q, Yu L L, Wang Y, et al. Inorg. Chem., 2013,52(6): 2817-2822 doi: 10.1021/ic301579g
12. [12]
  Nagarathinam M, Saravanan K, Phua E J H, et al. Angew. Chem. Int. Ed., 2012,124(24):5968-5972 doi: 10.1002/ange.201200210
13. [13]
  Shi C, Xia Q, Xue X, et al. RSC Adv., 2016,6(6):4442-4447 doi: 10.1039/C5RA22038F
14. [14]
  Liu X, Shi C, Zhai C, et al. ACS Appl. Mater. Interfaces, 2016,8(7):4585-4591 doi: 10.1021/acsami.5b10781
15. [15]
  Liu Q, Liu X, Shi C, et al. Dalton Trans., 2015,44(44):19175-19184 doi: 10.1039/C5DT02918J
16. [16]
  Su Z, Chen M, Okamura T, et al. Inorg. Chem., 2011,50(3): 985-991 doi: 10.1021/ic101618n
17. [17]
  Zhang Z, Yoshikawa H, Awaga K. J. Am. Chem. Soc., 2014, 136(46):16112-16115 doi: 10.1021/ja508197w
18. [18]
  WANG Cui-Juan , MAO Kai-Li, DAI Hai-Yu. Chinese J. Inorg. Chem., 2015, 31(11):2221-2228
19. [19]
  Procopio E Q, Linares F, Montoro C, et al. Angew. Chem. Int. Ed., 2010,49(40):7308-7311 doi: 10.1002/anie.v49:40
20. [20]
  Montoro C, Linares F, Procopio E Q, et al. J. Am. Chem. Soc., 2011,133(31):11888-11891 doi: 10.1021/ja2042113
21. [21]
  Tu B, Pang Q, Ning E, et al. J. Am. Chem. Soc., 2015,137(42):13456-13459 doi: 10.1021/jacs.5b07687
22. [22]
  ZHAI Chang-Wei, CHENG Mei-Ling, HAN Wei, et al. Chinese J. Inorg. Chem., 2015,31(7):1409-1416
23. [23]
  Cheng M L, Han W, Liu Q, et al. J. Coord. Chem., 2014,67(2):215-226 doi: 10.1080/00958972.2013.879983
24. [24]
  REN Yan-Qiu, HAN Wei, CHENG Mei-Ling , et al. Chinese J. Inorg. Chem., 2014,30(11):2635-2644
25. [25]
  Wang L D, Tao F, Cheng M L, et al. J. Coord. Chem., 2012, 65(6):923-933 doi: 10.1080/00958972.2012.663494
26. [26]
  Chen L T, Tao F, Wang L D, et al. Z. Anorg. Allg. Chem., 2013,639(3/4):552-557
27. [27]
  Su S, Cheng M L, Ren Y, et al. Transition Met. Chem., 2014,39(5):559-566 doi: 10.1007/s11243-014-9833-x
28. [28]
  Cheng M L, Tao F, Chen L, et al. Inorg. Chim. Acta, 2015, 429(1):22-29
29. [29]
  Liu J, Cheng M L, Yu L L, et al. RSC Adv., 2016,6(57): 52040-52047 doi: 10.1039/C6RA10989F
30. [30]
  Xia Q, Ren Y, Cheng M L, et al. J. Coord. Chem., 2015,68(10):1688-1704 doi: 10.1080/00958972.2015.1020305
31. [31]
  Chen S, Cheng M L, Ren Y, et al. Z. Anorg. Allg. Chem., 2015,641(3/4):610-616
32. [32]
  LIU Xiu-Xiu, CHENG Mei-Ling, REN Yan-Qiu, et al. Chinese J. Inorg. Chem., 2015,31(3):611-618
33. [33]
  Sheldrick G M. SHELXS-97, Program for X-ray Crystal Structure Determination, University of Göttingen, Germany, 1997.
34. [34]
  Sheldrick G M. SHELXL-97, Program for X-ray Crystal Structure Determination, University of Göttingen, Germany, 1997.
35. [35]
  Gadzikwa T, Farha O K, Mulfort K L, et al. Chem. Commun., 2009:3720-3722
36. [36]
  Shi Z Q, Li Y Z, Guo Z J, et al. CrystEngComm, 2014,16(5): 900-909 doi: 10.1039/C3CE41966E
37. [37]
  Li M, Peng Y F, Zhao S, et al. RSC Adv., 2014,4(27):14241-14247 doi: 10.1039/c4ra00531g
