Thermal Conductivity of Graphene and Its Testing Methods

Li Kunwei ¹ ,
Liu Yawei ² ,
Zhang Jian ¹ ,
You Congya ³ ,
Tian Tian ³ ,
Zhang Bo ³ ,
Liu Danmin ³ ,
Chen Aibing ^2,, ,
Zhang Yongzhe ^3,,

1.
China National Institute of Standardization, Beijing 100191
2.
College of Chemical and Pharmaceutical Engineering, Hebei University of Science and Technology, Shijiazhuang 050018
3.
College of Materials Science and Engineering, Beijing University of Technology, Beijing 100124

Corresponding author: Chen Aibing, chen_ab@163.com Zhang Yongzhe, yzzhang@bjut.edu.cn
Received Date: 29 October 2016
Accepted Date: 27 March 2017

Figures(10)

Graphene has attracted great attention due to its excellent properties which is originated from its unique structure. In this paper, recent works on graphene thermal conduction have been summarized, and it seems that the defect, substrate used and the edge of graphene are the main factors which influence the thermal conduction property of graphene. In addition, the thermal conductivity modes simulated by molecular dynamics and non-equilibrium Green's function have also been included. Based on these theory modes, experimental methodology of the thermal conduction measurement of layered graphene were involved, and the results were provided.
- Graphene,
- Thermal conductivity,
- Theoretical model,
- Experimental methodology
