Interface Reconstruction Study by Functional Scanning Probe Microscope in Li-ion Battery Research

School of Advanced Materials, Peking University Shenzhen Graduate School, Shenzhen 518055, China

Corresponding author: Hai-Biao CHEN, chenhb@pkusz.edu.cn Feng PAN, panfeng@pkusz.edu.cn
Received Date: 26 January 2020
Accepted Date: 2 February 2020

Fund Project: the National Key R&D Program of China 2016YFB0700600Soft Science Research Project of Guangdong Province 2017B030301013Shenzhen Science and Technology Research Grant ZDSYS201707281026184

Figures(2)

Interfacial reaction is a critical factor of lithium ion battery, but is also complicated and difficult to characterize. Scanning probe microscope (SPM) is one of the most effective tools to reveal the interface reconstruction and interfacial properties (including the morphologies, mechanical properties and electricity properties) of energy material at nanoscale and at real time. In this paper, we briefly summarized the principles of AFM, conductive AFM(C-AFM) and Kelvin probe force microscope (KPFM), as well as their application to investigate the interface reconstruction of lithium-ion battery electrode material.
