Citation: Bohao Liu, Xue Jiang, Ruizhi Ning, Heng Zhao, Yanpeng Zhang, Junnan Zhang, Tianqing Liu, Danyao Qu, Yinhui Bao, Zhanchen Guo, Xiaoyan Zeng, Shan Gao, Kun Fan, Runyi Tao, Jian Ji, Guangjian Zhang, Weiwei Wu. Tedlar bag free: Accurate volatolomics of ⅠA stage non-small cell lung cancer come out in wash[J]. Chinese Chemical Letters, ;2025, 36(6): 110301. doi: 10.1016/j.cclet.2024.110301 shu

Tedlar bag free: Accurate volatolomics of ⅠA stage non-small cell lung cancer come out in wash

Bohao Liu ^{a, g, 1} ,
Xue Jiang ^{b, c, 1} ,
Ruizhi Ning ^{d, 1} ,
Heng Zhao ^{a, g} ,
Yanpeng Zhang ^{a, g} ,
Junnan Zhang ^{b, c} ,
Tianqing Liu ^d ,
Danyao Qu ^{b, c} ,
Yinhui Bao ^{b, c} ,
Zhanchen Guo ^{b, c} ,
Xiaoyan Zeng ^e ,
Shan Gao ^a ,
Kun Fan ^a ,
Runyi Tao ^a ,
Jian Ji ^{f, *,} ,
Guangjian Zhang ^{a, g, *,} ,
Weiwei Wu ^{b, c, d, *,}

a.
Department of Thoracic Surgery, The First Affiliated Hospital of Xi’an Jiaotong University, Xi’an 710061, China
b.
Shaanxi Key Laboratory of High-Orbits-Electron Materials and Protection Technology for Aerospace, School of Advanced Materials and Nanotechnology, Xidian University, Xi’an 710126, China
c.
State Key Laboratory of Electromechanical Integrated Manufacturing of High-performance Electronic Equipments, Xidian University, Xi’an 710126, China
d.
Key Laboratory of Artificial Olfaction of Shaanxi Higher Education Institutes, Interdisciplinary Research Center of Smart Sensors, Academy of Advanced Interdisciplinary Research, Xidian University, Xi’an 710126, China
e.
Department of Laboratory Medicine, The First Affiliated Hospital of Xi’an Jiaotong University, Xi’an 710126, China
f.
State Key Laboratory of Food Science and Technology, National Engineering Research Center for Functional Foods, Jiangnan University, Wuxi 214122, China
g.
Key Laboratory of Enhanced Recovery After Surgery of Integrated Chinese and Western Medicine, Administration of Traditional Chinese Medicine of Shaanxi Province, Xi’an 710061, China

jijian@jiangnan.edu.cn

michael8039@xjtu.edu.cn

wwwu@xidian.edu.cn

Received Date: 31 March 2024
Revised Date: 25 June 2024
Accepted Date: 29 July 2024
Available Online: 31 July 2024

Figures(3)

Breath analysis can be used to diagnose diseases non-invasively. Accurate measurement of volatolomics is critical for breath analysis to be a gold standard. Tedlar bags (TB) are often used to collect breath samples, but they emit contaminants that affect accuracy. This issue was overlooked in previous studies. We found contamination issues with TB (e.g., siloxanes and aromatic impurities) that affect the identification of volatile organic compounds (VOCs) due to impurities. Then, home-designed equipment (HD) made with poly-tetrafluoride (PTFE) and quartz glass for breath collection was developed and employed in clinical trials. 15 healthy individuals and 32 non-small cell lung cancer (NSCLC) patients at IA stage participated in this study. 610 VOCs can be collected through TB, which is less than HD (1109 VOCs), demonstrating that the inner wall of the TB easily adsorbs VOCs, leading to decreased detection concentrations. Otherwise, utilizing orthogonal partial least squares discriminant analysis (OPLS-DA), we identified chemical markers with significant discriminatory power (VIP > 1.5, P < 0.05). The HD method identified 12 target VOCs, surpassing the 3 target VOCs discerned by the TB method. A model combined with a machine learning algorithm for distinguishing early-stage lung cancer patients was established based on biomarkers, which were selected based on OPLS-DA. The results showed strong predictive capabilities for the HD-based model. It indicated that 12 biomarkers derived from the HD model were more effective in distinguishing NSCLC patients, with an AUC value of 0.92, compared to the AUC value of 0.5 from 3 markers obtained from the TB model. The sensitivity and specificity in the confusion matrix reached 100% and 80% for the HD test, but TB test reached only 40% and 60%. This work demonstrated that optimizing and standardizing VOCs collection methodology from breath of lung cancer patients is essential to identify actual volatiles, which could promote disease volatolomics worldwide.
- Volatolomics,
- Lung cancer,
- Volatile organic compounds,
- Exhaled breath analysis,
- GC-MS
1. [1]
  S. Bratulic, A. Limeta, S. Dabestani, Proc. Natl. Acad. Sci. U. S. A. 119 (2022) e2115328119. doi: 10.1073/pnas.2115328119
2. [2]
  G. Pacchioni, Nat. Rev. Mater. 7 (2022) 679. doi: 10.1038/s41578-022-00475-4
3. [3]
  M. Phillips, N. Altorki, J.H.M. Austin, J. Clin. Oncol. 23 (2005) 9510. doi: 10.1200/jco.2005.23.16_suppl.9510
4. [4]
  G. Peng, M. Hakim, Y.Y. Broza, Br. J. Cancer 103 (2010) 542–551. doi: 10.1038/sj.bjc.6605810
5. [5]
  M. Hakim, Y.Y. Broza, O. Barash, Chem. Rev. 112 (2012) 5949–5966. doi: 10.1021/cr300174a
6. [6]
  N. Kahn, O. Lavie, M. Paz, Nano Lett. 15 (2015) 7023–7028. doi: 10.1021/acs.nanolett.5b03052
7. [7]
  L. Pauling, A.B. Robinson, R. Teranishi, Proc. Natl. Acad. Sci. U. S. A. 68 (1971) 2374–2376. doi: 10.1073/pnas.68.10.2374
8. [8]
  G. Peng, U. Tisch, O. Adams, Nat. Nanotechnol. 4 (2009) 669–673. doi: 10.1038/nnano.2009.235
9. [9]
  X.A. Fu, M.X. Li, R.J. Knipp, Cancer Med. 3 (2014) 174–181. doi: 10.1002/cam4.162
10. [10]
  P.H. Tsou, Z.L. Lin, Y.C. Pan, Cancers 13 (2021) 1431. doi: 10.3390/cancers13061431
11. [11]
  F. Kamal, S. Kumar, M.R. Edwards, Am. J. Respir. Crit. Care Med. 204 (2021) 1075–1085. doi: 10.1164/rccm.202103-0660oc
12. [12]
  M.M.L. Steeghs, S.M. Cristescu, F.J.M. Harren, Physiol. Meas. 28 (2007) 73–84. doi: 10.1088/0967-3334/28/1/007
13. [13]
  D. Zanella, A. Henin, S. Mascrez, J. Sep. Sci. 45 (2022) 3542–3555. doi: 10.1002/jssc.202200164
14. [14]
  P.L. Kasper, A. Oxbøl, M.J. Hansen, J. Environ. Qual. 47 (2018) 246–253. doi: 10.2134/jeq2017.07.0289
15. [15]
  S. Ghosh, K. -H. Kim, J.R. Sohn, Sci. World J. 11 (2011) 2160–2177. doi: 10.1100/2011/529532
16. [16]
  O. Lawal, W.M. Ahmed, T.M.E. Nijsen, Metabolomics 13 (2017) 110. doi: 10.1007/s11306-017-1241-8
17. [17]
  G.B. Hanna, P.R. Boshier, S.R. Markar, JAMA Oncol. 5 (2019) 1070.
18. [18]
  I. Eriksson, E. Johansson, N. Kettaneh-Wold, S. Wold, Multi- and megavariate data analysis. Principles application, Umetrics Academy, Umeå, 2001.
19. [19]
  L. Pincigher, F. Valenti, C. Bergamini, Molecules 28 (2023) 238–264.
20. [20]
  P. Vernocchi, T. Gili, F. Conte, Int. J. Mol. Sci. 21 (2020) 8730. doi: 10.3390/ijms21228730
21. [21]
  A. Bajtarevic, C. Ager, M. Pienz, BMC Cancer 9 (2009) 348. doi: 10.1186/1471-2407-9-348
22. [22]
  S. Thangaleela, B.S. Sivamaruthi, P. Kesika, Sci. Pharm. 90 (2022) 57. doi: 10.3390/scipharm90040057
23. [23]
  X. Yu, H. Lin, Y. Wang, Onco Targets Ther. 11 (2018) 1833–1847. doi: 10.2147/ott.s155716
24. [24]
  F. Gahleitner, C. Guallar-Hoyas, C.S. Beardsmore, Bioanalysis 5 (2013) 2239–2247. doi: 10.4155/bio.13.184
25. [25]
  R. Kumar, A. Indrayan, Indian Pediatr. 48 (2011) 277–287. doi: 10.1007/s13312-011-0055-4
26. [26]
  A.P. Bradley, Pattern Recognit. 30 (1997) 1145–1159. doi: 10.1016/S0031-3203(96)00142-2
