Citation: Ran Wang, Chaozheng He, Weixing Chen, Chenxu Zhao, Jinrong Huo. Rich B active centers in Penta-B₂C as high-performance photocatalyst for nitrogen reduction[J]. Chinese Chemical Letters, ;2021, 32(12): 3821-3824. doi: 10.1016/j.cclet.2021.05.024 shu

Rich B active centers in Penta-B₂C as high-performance photocatalyst for nitrogen reduction

Ran Wang ^{a, b} ,
Chaozheng He ^{a, b, *,} ,
Weixing Chen ^{a, b, *,} ,
Chenxu Zhao ^{a, b} ,
Jinrong Huo ^c

a.
Institute of Environmental and Energy Catalysis, School of Materials Science and Chemical Engineering, Xi'an Technological University, Xi'an 710021, China
b.
Shaanxi Key Laboratory of Optoelectronic Functional Materials and Devices, School of Materials Science and Chemical Engineering, Xi'an Technological University, Xi'an 710021, China
c.
School of Sciences, Xi'an Technological University, Xi'an 710021, China

hecz2019@xatu.edu.cn

chenwx@xatu.edu.cn

Received Date: 15 March 2021
Revised Date: 8 April 2021
Accepted Date: 14 May 2021
Available Online: 26 May 2021

Figures(4)

The photocatalytic nitrogen reduction reaction (NRR) has mild reaction conditions and only requires sunlight energy as a driving force to replace the traditional ammonia synthesis method. We herein investigate the catalytic activity and selectivity on Penta-B₂C for NRR by using density functional theory calculations. Penta-B₂C is a semiconductor with an indirect bandgap (2.328 eV) and is kinetically stable based on molecular dynamic simulations. The optical absorption spectrum of Penta-B₂C is achieved in the ultraviolet and visible range. Effective light absorption is more conducive to generate photo-excited electrons and improving photocatalytic performances. Rich B atoms as activation sites in Penta-B₂C facilitate capturing N₂. The activated N₂ molecule prefers the side-on adsorption configuration on Penta-B₂C, which facilitates the subsequent reduction reaction. Among considered NRR mechanisms on Penta-B₂C, the best pathway prefers the enzymatic mechanism, only required a low onset potential of 0.23 V. The hydrogen evolution reaction is inhibited when the hydrogen adsorption concentration is increased or N₂ molecules first occupy the adsorption sites. Our results indicate Penta-B₂C is a highly reactive and selective photocatalyst for NRR. Our work provides theoretical insights into the experiments and has guiding significance to synthesize efficient NRR photocatalysts.
- Nitrogen reduction,
- Photocatalytic,
- Penta-B₂C,
- Mechanism,
- B active center
1. [1]
  X. Lv, W. Wei, F. Li, et al., Nano Lett. 19(2019) 6391-6399. doi: 10.1021/acs.nanolett.9b02572
2. [2]
  H. Yu, Z. Wang, D. Yang, et al., J. Mater. Chem. A 7(2019) 12526-12531. doi: 10.1039/C9TA03297E
3. [3]
  C. Guo, J. Ran, A. Vasileff, et al., Energy Environ. Sci. 11(2018) 45-56. doi: 10.1039/C7EE02220D
4. [4]
  C. Ling, X. Bai, Y. Ouyang, et al., J. Phys. Chem. C 122(2018) 16842-16847. doi: 10.1021/acs.jpcc.8b05257
5. [5]
  L. Chen, C. He, R. Wang, et al., Chin. Chem. Lett. 32(2021) 53-56. doi: 10.1016/j.cclet.2020.11.013
6. [6]
  M.H. Vu, M. Sakar, S.A. Hassanzadeh-Tabrizi, et al., Adv. Mater. Interfaces 6(2019) 1900091. doi: 10.1002/admi.201900091
7. [7]
  F. Jiao, B. Xu, Adv. Mater. 31(2019) 1805173. doi: 10.1002/adma.201805173
8. [8]
  C. Ling, X. Niu, Q. Li, et al., J. Am. Chem. Soc. 140(2018) 14161-14168. doi: 10.1021/jacs.8b07472
9. [9]
  L. Shi, Y. Yin, S. Wang, et al., ACS Catal. 10(2020) 6870-6899. doi: 10.1021/acscatal.0c01081
10. [10]
  W. Zhao, B. Liu, J. Qin, et al., ChemPhotoChem 4(2020) 5322-5336. doi: 10.1002/cptc.202000114
11. [11]
  M. Cheng, C. Xiao, Y. Xie, J. Mater. Chem. A 7(2019) 19616-19633. doi: 10.1039/C9TA06435D
12. [12]
  Y. Yang, Y. Tang, H. Jiang, et al., Chin. Chem. Lett. 30(2019) 2089-2109. doi: 10.1016/j.cclet.2019.10.041
13. [13]
  C. Liu, Q. Li, J. Zhang, et al., J. Mater. Chem. A 7(2019) 4771-4776. doi: 10.1039/C8TA08219G
14. [14]
  J. Wang, Y.P. Liu, H. Zhang, et al., Catal. Sci. Technol. 9(2019) 4248-4254. doi: 10.1039/C9CY00907H
15. [15]
  Y. Wang, Q. Li, W. Shi, et al., Chin. Chem. Lett. 31(2020) 1768-1772. doi: 10.1016/j.cclet.2020.01.010
16. [16]
  Y. Lei, Y. Wang, Y. Liu, et al., Angew. Chem. Int. Ed. 59(2020) 20794-20812. doi: 10.1002/anie.201914647
17. [17]
  S. Liu, S. Wang, Y. Jiang, et al., Chem. Eng. J. 373(2019) 572-579. doi: 10.1016/j.cej.2019.05.021
18. [18]
  X. Mao, S. Zhou, C. Yan, et al., Phys. Chem. Chem. Phys. 21(2019) 1110-1116. doi: 10.1039/C8CP07064D
19. [19]
  W. He, X. Wu, Y. Li, et al., Chin. Chem. Lett. 31(2020) 2774-2778. doi: 10.1016/j.cclet.2020.07.019
20. [20]
  Y. Wang, Y. Liu, W. Liu, et al., Energy Environ. Sci. 13(2020) 4609-4624. doi: 10.1039/D0EE02833A
21. [21]
  L. Fu, R. Wang, C. Zhao, et al., Chem. Eng. J. 414(2021) 128857. doi: 10.1016/j.cej.2021.128857
22. [22]
  C. He, R. Wang, D. Xiang, et al., Appl. Surf. Sci. 509(2020) 145392. doi: 10.1016/j.apsusc.2020.145392
23. [23]
  X. Yu, P. Han, Z. Wei, et al., Joule 2(2018) 1610-1622. doi: 10.1016/j.joule.2018.06.007
24. [24]
  J. Yu, C. He, C. Pu, et al., Chin. Chem. Lett. 32(2021) 3149-3154. doi: 10.1016/j.cclet.2021.02.046
25. [25]
  H. Yang, C. He, L. Fu, et al., Chin. Chem. Lett. 32(2021) 3202-3206. doi: 10.1016/j.cclet.2021.03.038
26. [26]
  W. Song, J. Wang, L. Fu, et al., Chin. Chem. Lett. 32(2021) 3137-3142. doi: 10.1016/j.cclet.2021.02.043
27. [27]
  J. Wang, C. He, J. Huo, et al., Adv. Theory Simul. (2021) 2100003.
28. [28]
  M.A. Légaré, G. Bélanger-Chabot, R.D. Dewhurst, et al., Science 359(2018) 896-900. doi: 10.1126/science.aaq1684
29. [29]
  C.P. Zhang, B. Li, Z.G. Shao, Appl. Surf. Sci. 469(2019) 641-646. doi: 10.1016/j.apsusc.2018.11.072
30. [30]
  R. Krishnan, W.S. Su, H.T. Chen, Carbon 114(2017) 465-472. doi: 10.1016/j.carbon.2016.12.054
31. [31]
  H. Yuan, Z. Li, J. Yang, J. Mater. Chem. C 6(2018) 9055-9059. doi: 10.1039/C8TC03368D
32. [32]
  S. Zhang, J. Zhou, Q. Wang, et al., J. Phys. Chem. C 120(2016) 3993-3998.
33. [33]
  R. Krishnan, S.Y. Wu, H.T. Chen, Phys. Chem. Chem. Phys. 20(2018) 26414-26421. doi: 10.1039/C8CP04745F
34. [34]
  C. He, R. Wang, H. Yang, et al., Appl. Surf. Sci. 507(2020) 145076. doi: 10.1016/j.apsusc.2019.145076
35. [35]
  Y. Ying, K. Fan, X. Luo, et al., J. Mater. Chem. A 7(2019) 11444-11451. doi: 10.1039/C8TA11605A
36. [36]
  F. Li, K. Tu, H. Zhang, et al., Phys. Chem. Chem. Phys. 17(2015) 24151-24156. doi: 10.1039/C5CP03885E
37. [37]
  X. Fu, H. Yang, L. Fu, et al., Chin. Chem. Lett. 32(2021) 1089-1094. doi: 10.1016/j.cclet.2020.08.031
38. [38]
  R. Asahi, T. Morikawa, T. Ohwaki, et al., Science 293(2001) 269. doi: 10.1126/science.1061051
39. [39]
  Q. Wang, Y. Lei, D. Wang, et al., Energy Environ. Sci. 12(2019) 1730-1750. doi: 10.1039/C8EE03781G
40. [40]
  W. Gao, R. Huang, J Mech Phys Solids 66(2014) 42-58. doi: 10.1016/j.jmps.2014.01.011
41. [41]
  K. Dong, F. Huo, S. Zhang, Green Energy Environ. 5(2020) 251-258. doi: 10.1016/j.gee.2020.07.022
42. [42]
  X.Y. Xie, P. Xiao, W.H. Fang, et al., ACS Catal. 9(2019) 9178-9187. doi: 10.1021/acscatal.9b01551
43. [43]
  A. Liu, Y. Yang, D. Kong, et al., Appl. Surf. Sci. 536(2021) 147851. doi: 10.1016/j.apsusc.2020.147851
44. [44]
  X. Cui, C. Tang, Q. Zhang, Adv. Energy Mater. 8(2018) 1800369. doi: 10.1002/aenm.201800369
45. [45]
  E. Skúlason, T. Bligaard, S. Gudmundsdóttir, et al., Phys. Chem. Chem. Phys. 14(2012) 1235-1245. doi: 10.1039/C1CP22271F
46. [46]
  K. Bhattacharyya, A. Datta, Phys. Chem. Chem. Phys. 21(2019) 12346-12352. doi: 10.1039/C9CP00997C
47. [47]
  A.R. Singh, B.A. Rohr, J.A. Schwalbe, et al., ACS Catal. 7(2017) 706-709. doi: 10.1021/acscatal.6b03035
48. [48]
  L. Ju, Y. Dai, W. Wei, et al., Appl. Surf. Sci. 434(2018) 365-374. doi: 10.1016/j.apsusc.2017.10.172
49. [49]
  J. Liu, J. Phys. Chem. C 119(2015) 28417-28423. doi: 10.1021/acs.jpcc.5b09092
50. [50]
  S. Li, M. Shi, J. Yu, et al., Chin. Chem. Lett. 32(2021) 1977-1982. doi: 10.1016/j.cclet.2020.09.056
