Citation: Qi Wang, Hanqing Zhao, Boya Li, Chenhui Yang, Mingyang Li, Yanan Li, Peng Han, Miaomiao Wu, Tengyu Li, Ruiping Liu. MOF-derived Co₉S₈ nano-flower cluster array modified separator towards superior lithium sulfur battery[J]. Chinese Chemical Letters, ;2021, 32(3): 1157-1160. doi: 10.1016/j.cclet.2020.09.022 shu

MOF-derived Co₉S₈ nano-flower cluster array modified separator towards superior lithium sulfur battery

Department of Materials Science and Engineering, China University of Mining & Technology (Beijing), Beijing 100083, China

miaomwu@cumtb.edu.cn

lrp@cumtb.edu.cn

Received Date: 16 August 2020
Revised Date: 10 September 2020
Accepted Date: 15 September 2020
Available Online: 16 September 2020

Figures(4)

Lithium sulfur batteries with high energy density are thought to be the most potential energy storage technology that can be commercialized. However, the shuttle effect of polysulfides deteriorates its electrochemical performance. Herein, a novel Co₉S₈ nanostructure derived from metal organic framework material (MOF) was explored by simple liquid phase reaction and heat vulcanization of 2-methylimidazole and Co(NO₃)₂·6H₂O on the surface of the original PP separator. The Co₉S₈ nano-flower cluster array wall was vertically and closely arranged with the thickness of 200 nm, and the polysulfide can be adsorbed by its physical and chemical action to slow down the "shuttle effect". It is found that the cell with the modified separator can achieve an ideal discharge capacity of about 600 mAh/g at 1 C. The specific capacity is maintained at 500 mAh/g after 200 cycles, with only 0.11% of capacity decay per cycle. It provides a new way for the utilization of MOF material derivatives to modify the separator in order to improve the electrochemical performance of lithium-sulfur batteries.
