Citation: Zhao Qiuni, Duan Zaihua, Yuan Zhen, Li Xian, Wang Si, Liu Bohao, Zhang Yajie, Jiang Yadong, Tai Huiling. High performance ethylene sensor based on palladium-loaded tin oxide: Application in fruit quality detection[J]. Chinese Chemical Letters, ;2020, 31(8): 2045-2049. doi: 10.1016/j.cclet.2020.04.032 shu

High performance ethylene sensor based on palladium-loaded tin oxide: Application in fruit quality detection

Zhao Qiuni ^a ,
Duan Zaihua ^a ,
Yuan Zhen ^a ,
Li Xian ^b ,
Wang Si ^a ,
Liu Bohao ^a ,
Zhang Yajie ^a ,
Jiang Yadong ^a ,
Tai Huiling ^a,*,

a.
State Key Laboratory of Electronic Thin Films and Integrated Devices, School of Optoelectronic Science and Engineering, University of Electronic Science and Technology of China (UESTC), Chengdu 610054, China
b.
Agricultural Information Institute, Chinese Academy of Agricultural Sciences, Key Laboratory of Agricultural Information Service Technology of Ministry of Agriculture, Beijing 100081, China

taitai1980@uestc.edu.cn

Received Date: 13 January 2020
Revised Date: 17 February 2020
Accepted Date: 18 February 2020
Available Online: 1 May 2020

Figures(4)

Ethylene (C₂H₄), as a plant hormone, its emission can be served as an indicator to measure fruit quality. Due to the limited physiochemical reactivity of C₂H₄, it is a challenge to develop high performance C₂H₄ sensors for fruit detection. Herein, this paper presents a resistive-type C₂H₄ sensor based on Pd-loaded tin oxide (SnO₂). The C₂H₄ sensing performance of proposed sensor are tested at optimum operating temperature (250 ℃) with ambient relative humidity (51.9% RH). The results show that the response of Pd-loaded SnO₂ sensor (11.1, R_a/R_g) is about 3 times higher than that of pristine SnO₂ (3.5) for 100 ppm C₂H₄. The response time is also significantly shortened from 7 s to 1 s compared with pristine SnO₂. Especially, the Pd-loaded SnO₂ sensor possesses good sensitivity (0.58 ppm^-1) at low concentration (0.05-1 ppm) with excellent linearity (R²=0.9963) and low detection limit (50 ppb). The high sensing performance of Pd-loaded SnO₂ are attributed to the excellent adsorption and catalysis effects of Pd nanoparticle. Meaningfully, the potential applications of C₂H₄ sensor are performed for monitoring the maturity and freshness of fruits, which presents a promising prospect in fruit quality evaluation.
- Ethylene sensing,
- Pd-loaded SnO₂,
- High performance,
- Low detection limit,
- Fruit quality monitoring
