Citation: Tang Lei, Xu Pengcheng, Li Ming, Yu Haitao, Li Xinxin. H₂S gas sensor based on integrated resonant dual-microcantilevers with high sensitivity and identification capability[J]. Chinese Chemical Letters, ;2020, 31(8): 2155-2158. doi: 10.1016/j.cclet.2020.01.018 shu

H₂S gas sensor based on integrated resonant dual-microcantilevers with high sensitivity and identification capability

Tang Lei ^a,b ,
Xu Pengcheng ^b ,
Li Ming ^b ,
Yu Haitao ^b,*, ,
Li Xinxin ^b

a.
College of Life and Environmental Sciences, Shanghai Normal University, Shanghai 200234, China
b.
State Key Lab of Transducer Technology, Shanghai Institute of Microsystem and Information Technology, Chinese Academy of Sciences, Shanghai 200050, China

yht@mail.sim.ac.cn

Received Date: 23 December 2019
Revised Date: 5 January 2020
Accepted Date: 8 January 2020
Available Online: 8 January 2020

Figures(9)

Detection of trace-level hydrogen sulfide (H₂S) gas is of great importance whether in industrial production or disease diagnosis. This research presents a novel H₂S gas sensor based on integrated resonant dual-microcantilevers which can identify and detect trace-level H₂S in real-time. The sensor consists of two integrated resonant microcantilever sensors with different functions. One cantilever sensor can identify H₂S by outputting positive frequency shift signals, while the other cantilever sensor will detect H₂S as a normally used cantilever sensor with negative frequency shifts. Combined the two cantilever sensors, the proposed gas sensor can distinguish H₂S from a variety of common gases, and the detection limit to H₂S of the sensor is as sensitive as below 1 ppb.
