Citation: Zhao Yujun, Li Sijia, Wang Zheng, Wang Shengnian, Wang Shengping, Ma Xinbin. New ZnCe catalyst encapsulated in SBA-15 in the production of 1, 3-butadiene from ethanol[J]. Chinese Chemical Letters, ;2020, 31(2): 535-538. doi: 10.1016/j.cclet.2019.04.038 shu

New ZnCe catalyst encapsulated in SBA-15 in the production of 1, 3-butadiene from ethanol

Zhao Yujun ^a,*, ,
Li Sijia ^a ,
Wang Zheng ^a ,
Wang Shengnian ^b,*, ,
Wang Shengping ^a ,
Ma Xinbin ^a

a.
Key Laboratory for Green Chemical Technology of Ministry of Education. Collaborative Innovation Center of Chemical Science and Engineering, School of Chemical Engineering and Technology, Tianjin University, Tianjin 300072, China
b.
Chemical Engineering, Institute for Micromanufacturing, Louisiana Tech University, Ruston, LA 71272, United States

yujunzhao@tju.edu.cn

swang@latech.edu

Received Date: 14 March 2019
Revised Date: 11 April 2019
Accepted Date: 16 April 2019
Available Online: 17 April 2019

Figures(5)

ZnO-CeO₂/SBA-15 catalysts were prepared by two kinds of solid-state grinding method and used for the production of 1, 3-butadiene (1, 3-BD) from ethanol. A mixture of SBA-15 (with or without organic template) and metal precursors were ground in solid-state. The obtained catalysts were characterized by TG, N₂ adsorption-desorption, TEM, XRD, Py-FTIR and NH₃-TPD techniques. Superior dispersion of metal oxides and more exposed acid sites were achieved on the catalyst 10Zn₁Ce₅-AS with the presence of organic template in SBA-15 during the solid-state grinding process. The catalytic performance was evaluated in a fixed-bed reactor and a 1, 3-butadiene selectivity of as high as 45% is achieved. This is attributed to the coupling effect of Zn and Ce species in the mesopores of SBA-15, in which Zn promotes ethanol dehydrogenation and Ce enhances aldol-condensation, respectively. Additionally, solvent-free method inspires new catalyst synthesis strategy for the production of 1, 3-butadiene from ethanol.
- 1, 3-Butadiene,
- Ethanol,
- SBA-15,
- Dehydrogenation,
- Aldol-condensation
1. [1]
  E.V. Makshina, W. Janssens, B.F. Sels, P.A. Jacobs, Catal. Today 198(2012) 338-344. doi: 10.1016/j.cattod.2012.05.031
2. [2]
  H.X. Zhang, Y. Li, C.Q. Zhang, et al., Chin. Chem. Lett. 21(2010) 361-364.
3. [3]
  A. Walter, F. Rosillo-Calle, P. Dolzan, E. Piacente, K. Borges da Cunha, Biomass Bioenerg. 32(2008) 730-748. doi: 10.1016/j.biombioe.2008.01.026
4. [4]
  J.M. Otero, G. Panagiotou, L. Olsson, Adv. Biochem. Eng. Biotechnol. 108(2007) 1-40.
5. [5]
  W.J. Toussaint, J.T. Dunn, D.R. Jachson, Ind. Eng. Chem. Res. 39(1947) 120-125. doi: 10.1021/ie50446a010
6. [6]
  G. Pomalaza, M. Capron, V. Ordomsky, F. Dumeignil, Catalysts 6(2016) 203. doi: 10.3390/catal6120203
7. [7]
  H.E. Jones, E.E. Stahly, B.B. Corson, J. Am. Chem. Soc. 71(1949) 1822-1828. doi: 10.1021/ja01173a084
8. [8]
  C. Angelici, M.E. Velthoen, B.M. Weckhuysen, P.C. Bruijnincx, ChemSusChem 7(2014) 2505-2515. doi: 10.1002/cssc.201402361
9. [9]
  V.L. Sushkevich, I.I. Ivanova, V.V. Ordomsky, E. Taarning, ChemSusChem 7(2014) 2527-2536. doi: 10.1002/cssc.201402346
10. [10]
  W. Janssens, E.V. Makshina, P. Vanelderen, et al., ChemSusChem 8(2015) 994-1008. doi: 10.1002/cssc.201402894
11. [11]
  O.V. Larina, P.I. Kyriienko, S.O. Soloviev, Catal. Lett. 145(2015) 1162-1168. doi: 10.1007/s10562-015-1509-4
12. [12]
  T. Yan, W. Dai, G. Wu, et al., ACS Catal. 8(2018) 2760-2773. doi: 10.1021/acscatal.8b00014
13. [13]
  V.L. Sushkevich, D. Palagin, I.I. Ivanova, ACS Catal. 5(2015) 4833-4836. doi: 10.1021/acscatal.5b01024
14. [14]
  G.M. Cabello González, R. Murciano, A.L. Villanueva Perales, et al., Appl. Catal. A-Gen. 570(2019) 96-106. doi: 10.1016/j.apcata.2018.11.010
15. [15]
  P. Müller, S.P. Burt, A.M. Love, et al., ACS Catal. 6(2016) 6823-6832. doi: 10.1021/acscatal.6b01642
16. [16]
  Q. Zhu, B. Wang, T. Tan, ACS Sustain. Chem. Eng. 5(2016) 722-733.
17. [17]
  T. De Baerdemaeker, M. Feyen, U. Müller, et al., ACS Catal. 5(2015) 3393-3397. doi: 10.1021/acscatal.5b00376
18. [18]
  W. Dai, S. Zhang, Z. Yu, et al., ACS Catal. 7(2017) 3703-3706. doi: 10.1021/acscatal.7b00433
19. [19]
  T.W. Kim, J.W. Kim, S.Y. Kim, et al., Chem. Eng. J. 278(2015) 217-223. doi: 10.1016/j.cej.2014.09.110
20. [20]
  J.L. Cheong, Y. Shao, S.J.R. Tan, et al., ACS Sustain. Chem. Eng. 4(2016) 4887-4894. doi: 10.1021/acssuschemeng.6b01193
21. [21]
  V.L. Sushkevich, I.I. Ivanova, E. Taarning, Green Chem. 17(2015) 2552-2559. doi: 10.1039/C4GC02202E
22. [22]
  D. Zhao, J. Feng, Q. Huo, et al., Science. 279(1998) 548-552. doi: 10.1126/science.279.5350.548
23. [23]
  F. Kleitz, W. Schmidt, F. Schüth, Microporous Mesoporous Mater. 65(2003) 1-29. doi: 10.1016/S1387-1811(03)00506-7
24. [24]
  Y. Xu, Q. Jiang, Y. Cao, et al., Adv. Funct. Mater. 14(2004) 1113-1123. doi: 10.1002/adfm.200400009
25. [25]
  Q. Jiang, Z.Y. Wu, Y.M. Wang, et al., J. Mater. Chem. A. 16(2006) 1536-1542. doi: 10.1039/b516061h
26. [26]
  S.A. Bagshaw, J. Mater. Chem. A. 11(2001) 831-840. doi: 10.1039/b003592k
27. [27]
  R. Schmidt, E.W. Hansen, M. Stacker, D. Akporiaye, O.H. Ellestad, J. Am. Chem. Soc. 117(1995) 4049-4056. doi: 10.1021/ja00119a021
28. [28]
  A. Yin, X. Guo, W.L. Dai, K. Fan, J. Phys. Chem. C 113(2009) 11003-11013. doi: 10.1021/jp902688b
29. [29]
  Y. Wang, J. Liao, J. Zhang, et al., AICHE J. 63(2017) 2839-2849. doi: 10.1002/aic.15620
30. [30]
  Y.M. Wang, Z.Y. Wu, L.Y. Shi, J.H. Zhu, Adv. Mater. 17(2005) 323-327. doi: 10.1002/adma.200400860
31. [31]
  G. Pomalaza, G. Vofo, M. Capron, F. Dumeignil, Green Chem. 20(2018) 3203-3209. doi: 10.1039/C8GC01211C
