Metal-Organic Framework-Derived Fe-N-C Nanohybrids as Highly-Efficient Oxygen Reduction Catalysts

• WANG Qianqian ,
• LIU Dajun ,
• HE Xingquan ^,

• Department of Chemistry and Chemical Engineering, Changchun University of Science and Technology, Changchun 130022, P. R. China

Corresponding author: HE Xingquan, hexingquan@hotmail.com

• Received Date: 03 September 2018
  Accepted Date: 30 October 2018
  Revised Date: 29 October 2018
  Available Online: 15 July 2019
• Fund Project:

  The project was supported by the Natural Science Foundation of Jilin Province, China (20160101298 JC)

Abstract: Environmentally friendly and renewable energy technologies, such as fuel cells and metal-air batteries, hold great promise for solving current energy and environmental challenges. The oxygen reduction reaction (ORR) plays a pivotal role in this top-drawer question. However, the sluggish kinetics of the ORR and prohibitive costs limit the global scalability of such devices. Traditionally, platinum-based electrocatalysts exhibit the best performance for ORRs in both acid and alkaline electrolytes. However, to significantly reduce the cost and realize sustainable development, utilization of Pt must be replaced or significantly reduced in the ORR cathode for fuel cell applications. Therefore, developing earth-abundant and high-performance non-precious metal catalysts (NPMCs) for ORR is of critical importance for the commercialization of fuel cells. In comparison to traditional catalysts, metal-organic frameworks (MOFs) are ideal precursors that integrate metal, nitrogen, and carbon functionalities together into one ordered 3D crystal structure. MOFs, assembled by secondary building of units comprised of metals and organic linkers with strong bonding, have received significant research attention because they possess permanent porosity, a three-dimensional (3D) structure, and can be prepared using a diversity of metals and organic linkers. High surface area, and microporous carbon materials can be easily obtained by carbonization of MOFs at high temperatures. In particular, MOF-derived carbon nanocomposites, which were prepared from transition metals, and have the form M-N-C (M = Fe or Co), have demonstrated remarkably improved catalytic activity and stability. Herein, we report an NPMC material consisting of Fe₃C nanoparticles encapsulated in mesoporous N-doped carbon (Fe-N-C), synthesized by a simple strategy involving physical mixing of MIL-100(Fe) with glucose and urea, and subsequent pyrolysis under inert atmosphere. The strong interaction between metal atoms and nitrogen atoms is beneficial in generating more active sites, and sites with a higher intrinsic catalytic activity, via carbonization. The as-obtained catalysts exhibit remarkable ORR activity in alkaline media, with the best catalyst (Fe-N-C-900, which is synthesized at 900 ℃) featuring a more positive onset potential (0.96 V vs the reversible hydrogen electrode (RHE)), a more positive half-wave potential (0.83 V vs RHE), a much higher diffusion limiting current density (6.28 mA·cm^-2) and a larger electron-transfer number (n), even at low overpotentials, compared with other contrast materials. Fe-N-C-900's excellent catalytic activity and stability in ORR are due to its large BET surface area, its large total pore volume, its nitrogen dopants, its active Fe₃C nanoparticles and the cooperative effects among its reactive functionalities.
